Airtac 6V-F Base 6V100M12F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Mounting Base 6V100M12F Technical Details
- Model: 6V100M12F (6V-F Series)
- Compatible Cylinder Series: MY1/MY3/MY2H Standard ISO Cylinders
- Mounting Type: Side-mount flange with through-hole design
- Material: Aluminum alloy ADC12
- Surface Treatment: Black anodized oxidation
- Port Thread Size: M12×1.25 (Pneumatic connection)
- Mounting Hole Quantity: 4 precision-machined slots
- Hole Spacing: 80mm × 40mm (Center-to-center distance)
- Weight: 520g ±10g
- Dimensions: 98mm(L) × 42mm(W) × 25mm(H)
- Temperature Range: -20℃ to 150℃ (Intermittent use)
- Surface Hardness: HV 120-150 (Anodized layer)
- Vibration Resistance: ≤49 m/s² (10-150Hz XYZ directions)
Precision-engineered mounting base with dual-plane alignment grooves for MY-series cylinders, featuring anti-loosening threaded inserts and corrosion-resistant coating. The asymmetric slot design enables flexible positioning adjustment (±2mm) during installation. Includes integrated air passage channels for simplified piping.
- Robotic welding fixture positioning systems
- Palletizing machine vertical axis stabilization
- CNC tool changer cylinder mounting
- Pharmaceutical blister packaging linear actuators
- Automotive assembly line clamping units
Installation protocol:
Apply 0.3-0.5Nm torque during screw fastening. Use shim washers on uneven surfaces.
Align cylinder rod axis within ±0.5° angular tolerance. Lubricate guide slots with silicone grease (JIS K2220).
| Property | Property Value |
|---|---|
| sku | 6V100M12F |
