Airtac 6V-F Base 6V100M14F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base 6V100M14F Technical Specifications
- Model: 6V100M14F
- Series: 6V-F Modular Valve Base
- Port configuration: 4-port (P, A, B, R)
- Port size: G1/4 (BSPP thread)
- Mounting pattern: ISO 15407-1 / VDMA 24562 compliant
- Material: Aluminum alloy (anodized surface treatment)
- Operating pressure: 0.1–1.0 MPa
- Temperature range: -5℃ to 60℃
- Seal material: NBR (Nitrile rubber)
- Weight: 820g ±2%
- Dimensions: 100mm(L) × 50mm(W) × 34mm(H)
- Surface roughness: Ra ≤3.2μm
- Compatible valves: 3V/4V/5V series solenoid valves
- Stacking capability: Up to 16 units in series
Modular aluminum base designed for multi-valve manifold assemblies, featuring precision-machined flow channels and leak-proof sealing. The T-slot mounting system enables tool-free valve installation and supports horizontal/vertical manifold configurations. Includes integrated silencer ports and auto-bleed function for rapid pressure release.
- Centralized pneumatic control systems
- Automated assembly line manifolds
- Plastic injection molding machines
- Robotic end-effector control units
- Semiconductor manufacturing equipment
Installation protocol:
Apply ISO VG15 equivalent lubricant to sealing surfaces before assembly.
Torque mounting screws to 1.5N·m in crisscross pattern. Maintain ambient
humidity below 85% RH to prevent oxidation.
- End plate requirement: Use 6V-EP series at manifold extremities
- Maximum flow rate: 850 NL/min at 0.5 MPa
- Pressure drop: ≤0.02 MPa at rated flow
| Property | Property Value |
|---|---|
| sku | 6V100M14F |
