Airtac 6V-F Base 6V100M19F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base 6V100M19F Technical Specifications
- Full model designation: 6V100M19F (6V-F series)
- Base type: Universal mounting base for 6V series valves
- Port configuration: 5 ports (P, A, B, R1, R2)
- Port thread size: PT1/4 (G1/4 optional)
- Compatible valve models: 6V110, 6V120, 6V130 series
- Mounting pattern: ISO 15407-1 compliant
- Body material: Aluminum alloy ADC12 with anodized surface
- Operating pressure range: 0.15-0.8 MPa (21.7-116 PSI)
- Temperature resistance: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: Oil-resistant NBR (Nitrile rubber)
- Weight: 215g ±5g (without manifold connection)
- Dimensions: 100mm(L) × 40mm(W) × 25mm(H)
- Surface roughness: Ra 3.2μm (sealing surfaces)
- Protection class: IP54 (dust protected, water splashed)
Precision-machined manifold base designed for multi-valve stacking in modular pneumatic systems. Features dual-row O-ring sealing channels and anti-vibration mounting points. The diamond-shaped flow channels reduce pressure drop by 18% compared to conventional designs. Compatible with all 6V series valves using M5 manifold screws (torque spec: 0.7-0.9 N·m).
- Modular pneumatic control stations in automotive assembly lines
- Multi-axis robotic end effector control systems
- Packaging machinery with sequential valve operations
- Semiconductor handling equipment requiring vibration damping
- Plastic injection molding machine hydraulic-pneumatic interfaces
Installation protocol:
Apply thread sealant (Loctite 545 recommended) on manifold screws.
Maximum stacking height: 6 bases. Use alignment pins during multi-layer
assembly to prevent port misalignment. Allow 15mm clearance below base
for tubing connections.
| Property | Property Value |
|---|---|
| sku | 6V100M19F |
