AirTAC ACEJ Series · ISO 21287 Compact Cylinder

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B

The AirTAC ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B is a genuine double acting, double rod, adjustable stroke ISO 21287 compact air cylinder with a Ø125mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.

  • BoreØ125 mm
  • Stroke10 mm
  • Port size1/4"
  • Acting typeDouble acting, double rod, adjustable stroke
  • Rod threadM16×2.0
  • CushionFixed TPU bumper (both ends)
$182.48 $198.48Save 8% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACEJ125 stroke, adjustment, mounting and version on one page All ACEJ125 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B

A double acting AirTAC compact cylinder built to ISO 21287, the ACEJ125X10-10B pairs a 125 mm bore with a short 10 mm stroke and a male rod thread (B code). At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N, rising to 8590.3 N on the extend stroke at 0.7 MPa - the heaviest force class in the ACEJ range. The -10 suffix is a 10 mm adjustment window: an external stop screw trims the extend stroke on site anywhere from 0 to 10 mm, so one cylinder can be dialled to several clamping or ejection positions without re-plumbing.

The hard-anodized aluminium body with an S45C hard-chrome plated 25 mm rod shrugs off wear in high-cycle presses and forming fixtures. Because the short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, it slots into press dies and heavy gantries where a full-length body cannot. A fixed TPU bumper at each end absorbs end-of-stroke impact. Note that the stop screw sets the end position only - it is not a mid-stroke lock, so the piston still drifts if air is lost.

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B Technical Specifications

ModelAirtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B
SeriesACEJ compact cylinder
StandardISO 21287
Bore sizeØ125 mm
Stroke10 mm
Acting typeDouble acting, double rod, adjustable stroke
Port size1/4"
Rod threadM16×2.0
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed TPU bumper (both ends)
Max standard strokeUp to 300 mm

Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.

Theoretical Output Force (Ø125mm)

PressureForce (both ways)
0.5 MPa5890 N
0.7 MPa8247 N
Max (@1.0 MPa)1201 kgf

ACEJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).

Model Code: Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B

ACEJISO 21287 compact cylinder (adjustable-stroke).
125Bore size in mm.
×10Stroke length in mm.
-10Adjustable stroke window (mm the extend stroke can be shortened on site).
SOptional built-in magnet for CMSE / DMSE sensors (omit for no magnet).
BRod type: B = male thread; blank = female thread.

ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (double rod, adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.

Where the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B Is Used

vertical_align_bottom

Injection mould ejection

A short 10 mm kick ejects thick moulded parts from large tools; the male rod thread (B) bolts directly to ejector plates without adapters.

Is the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B the Right Cylinder?

At this bore there is nothing larger in the range - the 125 mm ACEJ is the top of the line, delivering 6135.9 N at 0.5 MPa where a 100 mm bore gives 3927.0 N. If your load needs under 4000 N, step down to the 100 mm bore and save air consumption. The 10 mm stroke with a 10 mm trim window suits short-throw work such as die spotting, part ejection or heavy clamping. Order the -S code if you need the optional magnet for CMSE / DMSE switches; this model without S has no magnet fitted. Mount with FA flange or LB foot on the ISO 21287 face, and choose G thread instead of PT if your plant uses parallel ports.

AirtacDistr lists every ACEJ125 order code with its price on one page at https://airtacdistr.com/products/airtac-acej125-adjustable-double-rod-compact-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Short stroke fits the compact body
  • ✓ Port/thread type (PT / G)
  • ✓ Add -S if you need the magnet for sensors
  • ✓ Rod type (female / male B) & mount (FA/LB/CA)
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Compact body: keep the stroke short and avoid side load on the rod.
  • check Do not dismantle the threaded front/back covers.
  • check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10B FAQ

At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N; at 0.7 MPa push is 8590.3 N and pull 8246.7 N, with a theoretical maximum of 1251.4 kgf at 1.0 MPa. The -10 code gives a 10 mm adjustment window: an external stop screw shortens the 10 mm extend stroke anywhere from 0 to 10 mm. It sets the end position only and does not hold a load if air pressure drops. Operating range is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, port 1/4" PT, rod end male thread.

The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits tight dies and guarded machines. A fixed TPU bumper at each end absorbs end-of-stroke impact. Position sensing needs the optional -S magnet code: with -S ordered, CMSE or DMSE switches mount in the body slots; this model, ordered without S, carries no magnet, so no switch can be read. FA flange and LB foot mount on the standard ISO 21287 face.
