AirTAC ACEJ Series · ISO 21287 Compact Cylinder

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B

The AirTAC ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B is a genuine double acting, double rod, adjustable stroke ISO 21287 compact air cylinder with a Ø125mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.

  • BoreØ125 mm
  • Stroke100 mm
  • Port size1/4"
  • Acting typeDouble acting, double rod, adjustable stroke
  • Rod threadM16×2.0
  • CushionFixed TPU bumper (both ends)
$221.47 $240.10Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACEJ125 stroke, adjustment, mounting and version on one page All ACEJ125 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B

The ACEJ125X100-10B is a double acting ISO 21287 compact cylinder with an adjustable extend stroke: an external stop screw trims the 100 mm stroke by up to 10 mm on site, giving a usable range of 90-100 mm. At 125 mm bore it is the largest size in the series, pushing 6135.9 N and pulling 5890.5 N at 0.5 MPa, rising to 8590.3 N at 0.7 MPa. The male rod thread (B code) on the 25 mm rod bolts straight into existing tooling.

The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so this force class fits into heavy presses and clamping fixtures without a full-length body. A hard-anodized aluminium body, S45C hard-chrome rod and fixed TPU bumpers at both ends handle 0.15-1.0 MPa (22-145 psi) air at speeds of 30-500 mm/s.

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B Technical Specifications

ModelAirtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B
SeriesACEJ compact cylinder
StandardISO 21287
Bore sizeØ125 mm
Stroke100 mm
Acting typeDouble acting, double rod, adjustable stroke
Port size1/4"
Rod threadM16×2.0
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed TPU bumper (both ends)
Max standard strokeUp to 300 mm

Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.

Theoretical Output Force (Ø125mm)

PressureForce (both ways)
0.5 MPa5890 N
0.7 MPa8247 N
Max (@1.0 MPa)1201 kgf

ACEJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).

Model Code: Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B

ACEJISO 21287 compact cylinder (adjustable-stroke).
125Bore size in mm.
×100Stroke length in mm.
-10Adjustable stroke window (mm the extend stroke can be shortened on site).
SOptional built-in magnet for CMSE / DMSE sensors (omit for no magnet).
BRod type: B = male thread; blank = female thread.

ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (double rod, adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.

Where the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B Is Used

compress

Heavy press-fit station

A 90-100 mm adjustable extend stroke with 6135.9 N at 0.5 MPa seats bearings or bushings into aluminium housings on an automotive assembly line, with the stop screw dialing in the exact seating depth.

forklift

Pallet stamping marker

The male-thread 25 mm rod drives a heavy marking head into plywood pallets; 8590.3 N at 0.7 MPa gives crisp impressions even at 500 mm/s cycle speed.

Is the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B the Right Cylinder?

Remember the stop screw only shortens the extend stroke within the 10 mm window - it is not a mid-stroke lock, so on air loss the piston still drifts. Mounting: FA flange, LB foot or FTC brackets plus I/Y rod knuckles fit the ISO 21287 face. This unit has no magnet; order the -S code if you need CMSE / DMSE switch sensing.

AirtacDistr lists every ACEJ125 order code with its price on one page at https://airtacdistr.com/products/airtac-acej125-adjustable-double-rod-compact-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Short stroke fits the compact body
  • ✓ Port/thread type (PT / G)
  • ✓ Add -S if you need the magnet for sensors
  • ✓ Rod type (female / male B) & mount (FA/LB/CA)
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Compact body: keep the stroke short and avoid side load on the rod.
  • check Do not dismantle the threaded front/back covers.
  • check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10B FAQ

At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N; at 0.7 MPa it pushes 8590.3 N and pulls 8246.7 N, with a theoretical maximum of 1251.4 kgf at 1.0 MPa. The -10 code means an external stop screw shortens the 100 mm extend stroke by up to 10 mm, so the working range is 90-100 mm. It runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), proof pressure 1.5 MPa (215 psi), -20 to +70 C, 30-500 mm/s, with a 1/4" PT port and a male rod thread on the 25 mm rod.

The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits deep inside heavy fixtures. A fixed TPU bumper at each end absorbs end-of-stroke impact. FA flange, LB foot and FTC brackets plus I/Y rod knuckles bolt to the standard face. This model ships without a magnet; the optional -S magnet enables CMSE / DMSE switches for end-position sensing.
