The AirTAC ACEJ125 Adjustable Compact Cylinder ACEJ125X100-20B is a genuine double acting, double rod, adjustable stroke ISO 21287 compact air cylinder with a Ø125mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
The ACEJ125X100-20B is a double acting AirTAC compact cylinder built to ISO 21287, with a 125 mm bore and a 100 mm extend stroke that an external stop screw trims by up to 20 mm on site, giving a usable range of 80-100 mm. At 0.5 MPa it pushes with 6135.9 N and pulls with 5890.5 N, rising to 8590.3 N on the extend stroke at 0.7 MPa. The male rod thread (B code) on the 25 mm hard-chrome-plated S45C rod bolts straight to tooling plates.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so this 125 mm bore fits heavy presses and clamping fixtures where a full-length profile body would not. A fixed TPU bumper at each end absorbs end-of-stroke impact. Operating range is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, air filtered to 40 um.
| Model | Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-20B |
|---|---|
| Series | ACEJ compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø125 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | 1/4" |
| Rod thread | M16×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 5890 N |
| 0.7 MPa | 8247 N |
| Max (@1.0 MPa) | 1201 kgf |
ACEJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
| ACEJ | ISO 21287 compact cylinder (adjustable-stroke). |
|---|---|
| 125 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -20 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (double rod, adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
The male rod thread and FA flange interface drive heavy clamp arms and die locators on machining centres, where the compact body shortens the fixture envelope by about half versus an ISO 15552 profile cylinder.
A 125 mm bore gives the force to seat large mould cores and slides, and the stop screw lets toolmakers trim the 100 mm stroke in 20 mm of range without changing the cylinder.
Remember the stop screw only shortens the extend stroke within the 20 mm window and is a mechanical end stop, not a mid-stroke lock - on air loss the piston drifts, so add a separate holding valve for suspended loads. Mount via FA flange or LB foot on the ISO 21287 face, with I and Y rod knuckles available. This version has no magnet; order the -S code if you need CMSE / DMSE switch positioning.
AirtacDistr lists every ACEJ125 order code with its price on one page at https://airtacdistr.com/products/airtac-acej125-adjustable-double-rod-compact-cylinder
Quick checklist
At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N; at 0.7 MPa push is 8590.3 N and pull 8246.7 N, with a theoretical maximum of 1251.4 kgf at 1.0 MPa. The -20 code sets a 20 mm adjustment window: an external stop screw shortens the 100 mm extend stroke to any length from 80 to 100 mm. It runs double acting on 0.15-1.0 MPa (22-145 psi) air filtered to 40 um, at 30-500 mm/s, with a 1/4" port and a 25 mm male-thread rod.
It is an ISO 21287 compact cylinder with a hard-anodized aluminium body and threaded covers, saving about 50% of the mounting length of an ISO 15552 profile cylinder. A fixed TPU bumper at each end absorbs end-of-stroke energy. Mounting options include FA flange, LB foot, FTC brackets and I/Y rod knuckles on the standard ISO 21287 face. Position sensing requires the optional -S magnet code; this model (no S) has no magnet, so CMSE / DMSE switches cannot be fitted to it.
