Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-30B
$232.60
Regular price
$240.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ125X100-30B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 21287 standard for enhanced mounting dimension compatibility;
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
Installation note:
Optimal performance achieved when mounted horizontally (±5° tolerance).
Lubricate through air supply (ISO VG32 recommended) with 5-50μm filtration.
Cushion adjustment requires 2.5mm hex key (1/4 turn increments).
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-30B Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-30B
- Type: Double-acting adjustable cushion cylinder
- Bore size: Φ125mm
- Stroke: 100mm (customizable 25-500mm)
- Operating pressure: 0.15–0.8 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: MF1 (basic front flange)
- Port size: Rc1/4 (G1/4 optional)
- Piston rod thread: M20×1.5
- Material: Aluminum alloy body, NBR seals
- Protection rating: IP54 (standard dust/moisture resistance)
- Weight: 4.8kg ±2% (without accessories)
- Dimensions: 300mm(L) × 160mm(W) × 160mm(H)
High-efficiency compact cylinder featuring dual adjustable air cushions for smooth stroke-end deceleration. Precision-machined aluminum construction with chrome-plated piston rod (hardness HRC45-50) ensures durability in high-cycle applications. Integrated magnetic slot (D-M9) enables position sensing compatibility.
Typical Applications:
- Packaging machinery pusher mechanisms
- Automotive assembly line clamping devices
- Palletizing robot end-effectors
- Press tooling ejection systems
- Material handling gate actuators
Installation note:
Optimal performance achieved when mounted horizontally (±5° tolerance).
Lubricate through air supply (ISO VG32 recommended) with 5-50μm filtration.
Cushion adjustment requires 2.5mm hex key (1/4 turn increments).
Service Interval:
- Re-lubrication: Every 500,000 cycles
- Seal replacement: 3,000km cumulative travel
- Rod inspection: Monthly in high-contamination environments
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-30B |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
