The AirTAC ACEJ125 Adjustable Compact Cylinder ACEJ125X100-40B is a genuine double acting, double rod, adjustable stroke ISO 21287 compact air cylinder with a Ø125mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
A heavy-duty double acting compact cylinder built to ISO 21287, the ACEJ125X100-40B pairs a 125 mm bore with a 100 mm stroke and a 40 mm adjustment window. At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N, rising to 8590.3 N at 0.7 MPa, with a theoretical maximum of 1251.4 kgf at 1.0 MPa. The external stop screw trims the extend stroke anywhere in the 60-100 mm range on site, so one cylinder covers several die or fixture positions without reordering.
The hard-anodized aluminium body with an S45C hard-chrome plated 25 mm rod runs at 0.15-1.0 MPa (22-145 psi) and 30-500 mm/s, with fixed TPU bumpers at both ends. Its short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, which matters in presses and gantries where every millimetre of envelope counts. Note this model has no magnet; order the -S code if you need CMSE / DMSE switch positions.
| Model | Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-40B |
|---|---|
| Series | ACEJ compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø125 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod, adjustable stroke |
| Port size | 1/4" |
| Rod thread | M16×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 5890 N |
| 0.7 MPa | 8247 N |
| Max (@1.0 MPa) | 1201 kgf |
ACEJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).
| ACEJ | ISO 21287 compact cylinder (adjustable-stroke). |
|---|---|
| 125 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -40 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (double rod, adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Clamping large castings or weldments in CNC fixtures: the compact body saves about 50% of the mounting length of an ISO 15552 profile cylinder, freeing space inside tight fixture plates.
If your stroke must be set precisely at several positions, the 40 mm window here (60-100 mm usable) is the deciding feature. Mounting: FA flange or LB foot bolt to the ISO 21287 face, with I and Y rod knuckles available; the male (B) rod thread suits fixtures that accept a stud. The stop screw is a mechanical end stop only - on air loss the piston still drifts, so add a separate holding valve where a load must stay put.
AirtacDistr lists every ACEJ125 order code with its price on one page at https://airtacdistr.com/products/airtac-acej125-adjustable-double-rod-compact-cylinder
Quick checklist
It is double acting with a 100 mm stroke adjustable down to 60 mm via the stop screw, air supply 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, temperature -20 to +70 C, 1/4" PT port and a 25 mm male-thread rod (B code).
An external stop screw on the head shortens the extend stroke by up to 40 mm, giving a usable 60-100 mm range set with a wrench in minutes. The bumper at each end is a fixed TPU pad that only decelerates at end of stroke - it never locks or holds a load. Sensors need the optional -S magnet code; this model (no S) has no magnet, so order ACEJ125X100-40SB or -S to use CMSE / DMSE switches.
