AirTAC ACEJ Series · ISO 21287 Compact Cylinder

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B

The AirTAC ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B is a genuine double acting, double rod, adjustable stroke ISO 21287 compact air cylinder with a Ø125mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.

  • BoreØ125 mm
  • Stroke100 mm
  • Port size1/4"
  • Acting typeDouble acting, double rod, adjustable stroke
  • Rod threadM16×2.0
  • CushionFixed TPU bumper (both ends)
$221.47 $240.10Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACEJ125 stroke, adjustment, mounting and version on one page All ACEJ125 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B

The ACEJ125X100-50B is a double acting ISO 21287 compact cylinder with a 125 mm bore and a 100 mm stroke that an external stop screw trims by up to 50 mm on site, giving a usable extend range of 50-100 mm. At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N, rising to 8590.3 N at 0.7 MPa - the heaviest force class in the ACEJ range. The male rod thread (B code) on the 25 mm rod bolts straight into tooling plates.

The hard-anodized aluminium body with an S45C hard-chrome rod saves about 50% of the mounting length of an ISO 15552 profile cylinder, so this 125 mm muscle fits inside presses, clamping fixtures and gantries that cannot host a full-length body. Operating window: 0.15-1.0 MPa (22-145 psi), 30-500 mm/s, fixed TPU bumper at both ends.

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B Technical Specifications

ModelAirtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B
SeriesACEJ compact cylinder
StandardISO 21287
Bore sizeØ125 mm
Stroke100 mm
Acting typeDouble acting, double rod, adjustable stroke
Port size1/4"
Rod threadM16×2.0
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed TPU bumper (both ends)
Max standard strokeUp to 300 mm

Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.

Theoretical Output Force (Ø125mm)

PressureForce (both ways)
0.5 MPa5890 N
0.7 MPa8247 N
Max (@1.0 MPa)1201 kgf

ACEJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).

Model Code: Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B

ACEJISO 21287 compact cylinder (adjustable-stroke).
125Bore size in mm.
×100Stroke length in mm.
-50Adjustable stroke window (mm the extend stroke can be shortened on site).
SOptional built-in magnet for CMSE / DMSE sensors (omit for no magnet).
BRod type: B = male thread; blank = female thread.

ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (double rod, adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.

Where the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B Is Used

compress

Heavy press-fit and staking stations

With 6135.9 N at 0.5 MPa and 8590.3 N at 0.7 MPa, the 125 mm bore presses bearings, bushings and studs into housings; the 50 mm window lets the line set the exact bottom-of-stroke position per part.

factory

Clamping of large castings on machining fixtures

The short ISO 21287 body fits inside fixture frames where an ISO 15552 profile cylinder would overhang, while the male-threaded 25 mm rod takes heavy swing clamps directly.

Is the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B the Right Cylinder?

The -50 window suits fixtures where the stroke must be fine-tuned after installation; remember the stop screw only shortens the extend stroke and does not lock the piston if air is lost. Mounting: FA flange, LB foot and FTC brackets plus I/Y rod knuckles fit the ISO 21287 face. This unit has no magnet - order the -S code if CMSE / DMSE switches are needed.

AirtacDistr lists every ACEJ125 order code with its price on one page at https://airtacdistr.com/products/airtac-acej125-adjustable-double-rod-compact-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Short stroke fits the compact body
  • ✓ Port/thread type (PT / G)
  • ✓ Add -S if you need the magnet for sensors
  • ✓ Rod type (female / male B) & mount (FA/LB/CA)
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Compact body: keep the stroke short and avoid side load on the rod.
  • check Do not dismantle the threaded front/back covers.
  • check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50B FAQ

At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N; at 0.7 MPa push is 8590.3 N and pull 8246.7 N; theoretical maximum is 1251.4 kgf at 1.0 MPa. The -50 code is a 50 mm adjustment window: an external stop screw shortens the 100 mm extend stroke on site to any length from 50 to 100 mm. It is a mechanical end stop only - on air loss the piston still drifts, so it is not a load-holding brake. Air supply is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, with a fixed TPU bumper at both ends.

The ISO 21287 compact body saves about 50% of the mounting length of an ISO 15552 profile cylinder, and FA flange, LB foot and FTC brackets plus I/Y rod knuckles bolt to the standard face. Position sensing requires the optional -S magnet code: this model (no S) has no magnet, so CMSE or DMSE switches cannot be mounted unless you order the -S version. The 1/4" port is fixed by the 125 mm bore; rod end is a male thread (B code).
