AirTAC ACEJ Series · ISO 21287 Compact Cylinder

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B

The AirTAC ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B is a genuine double acting, double rod, adjustable stroke ISO 21287 compact air cylinder with a Ø125mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.

  • BoreØ125 mm
  • Stroke100 mm
  • Port size1/4"
  • Acting typeDouble acting, double rod, adjustable stroke
  • Rod threadM16×2.0
  • CushionFixed TPU bumper (both ends)
$221.47 $240.10Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACEJ125 stroke, adjustment, mounting and version on one page All ACEJ125 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B

The ACEJ125X100-75B is a double acting ISO 21287 compact cylinder with an adjustable extend stroke: an external stop screw trims the 100 mm stroke by up to 75 mm, giving a usable range of 25-100 mm on site. The male rod thread (B code) bolts straight into clevis-style tooling.

The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so this 125 mm bore fits presses and heavy clamping fixtures where a full-length profile cylinder will not. The hard-anodized aluminium body carries an S45C hard-chrome plated 25 mm rod, fixed TPU bumpers at both ends, and runs at 30-500 mm/s on 0.15-1.0 MPa (22-145 psi) filtered air.

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B Technical Specifications

ModelAirtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B
SeriesACEJ compact cylinder
StandardISO 21287
Bore sizeØ125 mm
Stroke100 mm
Acting typeDouble acting, double rod, adjustable stroke
Port size1/4"
Rod threadM16×2.0
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed TPU bumper (both ends)
Max standard strokeUp to 300 mm

Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.

Theoretical Output Force (Ø125mm)

PressureForce (both ways)
0.5 MPa5890 N
0.7 MPa8247 N
Max (@1.0 MPa)1201 kgf

ACEJ is double-rod: the rear rod that carries the stroke adjuster exits the rear cover, so both piston faces lose rod area. The rod-side (annular) area is used for both directions (conservative).

Model Code: Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B

ACEJISO 21287 compact cylinder (adjustable-stroke).
125Bore size in mm.
×100Stroke length in mm.
-75Adjustable stroke window (mm the extend stroke can be shortened on site).
SOptional built-in magnet for CMSE / DMSE sensors (omit for no magnet).
BRod type: B = male thread; blank = female thread.

ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (double rod, adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.

Where the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B Is Used

forklift

Pallet and die clamping on machining centres

Clamps heavy fixtures or die shoes in tight envelopes - the compact body saves about 50% of the mounting length of an ISO 15552 profile cylinder, and the male rod thread accepts standard knuckles.

Is the Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B the Right Cylinder?

Size down if you can: a 100 mm bore pushes 3927.0 N at 0.5 MPa, so pick it when your load stays under about 2350 N of real work. Note the stop screw is a mechanical end stop for the extend stroke only; on air loss the piston drifts, so add a separate valve or lock if the load must be held. Mount with FA flange or LB foot brackets on the ISO 21287 face, and order the optional -S magnet if you later need CMSE / DMSE switches - this model has no magnet fitted.

AirtacDistr lists every ACEJ125 order code with its price on one page at https://airtacdistr.com/products/airtac-acej125-adjustable-double-rod-compact-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Short stroke fits the compact body
  • ✓ Port/thread type (PT / G)
  • ✓ Add -S if you need the magnet for sensors
  • ✓ Rod type (female / male B) & mount (FA/LB/CA)
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Compact body: keep the stroke short and avoid side load on the rod.
  • check Do not dismantle the threaded front/back covers.
  • check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75B FAQ

At 0.5 MPa it pushes 6135.9 N and pulls 5890.5 N; at 0.7 MPa push rises to 8590.3 N (pull 8246.7 N), with a theoretical maximum of 1251.4 kgf at 1.0 MPa. The -75 code is the adjustment window: an external stop screw shortens the 100 mm extend stroke by up to 75 mm, so the working range is 25-100 mm. It runs double acting on 0.15-1.0 MPa (22-145 psi) air at 30-500 mm/s, with a 1/4" port and a 25 mm male-thread rod.

It is an ISO 21287 compact cylinder - about 50% shorter in mounting length than an ISO 15552 profile cylinder - with a hard-anodized aluminium body, S45C hard-chrome plated rod and threaded covers. Fixed TPU bumpers absorb end-of-stroke energy at both ends. Mounting uses FA flange or LB foot brackets on the standard ISO 21287 face. Position sensing requires the optional -S magnet code; this model has no magnet, so CMSE / DMSE switches cannot be fitted unless you order it.
