AirTAC ACQ Series · JIS Compact Cylinder

Airtac ACQ140 Compact Cylinder ACQ140X50SB

The AirTAC ACQ140 Compact Cylinder ACQ140X50SB is a genuine double-acting COMPACT (thin) air cylinder built to JIS dimensions, with a Ø140mm bore and 50mm stroke, PT3/8 air ports and a C-clip / riveted short body that saves mounting depth. Magnetic-switch slots around the body accept position sensors.

  • BoreØ140 mm
  • Stroke50 mm
  • Port sizePT3/8
  • Acting typeDouble acting
  • Rod threadM22×2.5 (F) / M30×1.5 (B)
  • ConfigurationBig-bore compact
$238.91 $246.41Save 3% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACQ140 stroke, mounting and version on one page All ACQ140 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACQ140 Compact Cylinder ACQ140X50SB

The AirTAC ACQ140X50SB is a double-acting, single-rod JIS compact cylinder engineered for heavy-duty tasks, delivering a substantial 7696.9 N of push force at 0.5 MPa. Part of the big-bore ACQ family, it utilizes a short C-clip and riveted piston-to-rod assembly to drastically minimize axial mounting depth compared to conventional round-body units. This space efficiency is critical when designing large-scale machinery with tight clearances.

This specific configuration includes a built-in piston magnet (S) for position sensing and a male-thread rod end (B) sized at M30x1.5 for direct load coupling. Deceleration is handled by a fixed NBR elastomer bumper at each end. Because this is a rigid buffer rather than an adjustable air cushion, high-energy impacts require slowing the approach speed or adding external shock absorbers.

Airtac ACQ140 Compact Cylinder ACQ140X50SB Technical Specifications

ModelAirtac ACQ140 Compact Cylinder ACQ140X50SB
SeriesACQ JIS compact (thin) cylinder
Bore sizeØ140 mm
Stroke50 mm
Acting typeDouble acting
Port sizePT3/8
Rod end threadM22×2.5 female / M30×1.5 male (B)
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionBumper (both ends)
Max standard strokeUp to 300 mm

Specifications follow the official AirTAC ACQ JIS compact-cylinder datasheet. Confirm against the product label before installation. Port thread: PT (standard); G and NPT available. Rod: female thread (blank) / male thread (B).

Theoretical Output Force (Ø140mm)

PressurePush forcePull force
0.5 MPa7697 N7295 N
0.7 MPa10776 N—
Max (@1.0 MPa)1570 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac ACQ140 Compact Cylinder ACQ140X50SB

ACQJIS compact (thin) double-acting cylinder series.
140Bore size in mm.
×50Stroke length in mm.
SBuilt-in magnet for magnetic-switch position sensing (omit = no magnet).
BMale-thread piston rod (omit = female-thread rod).

Thread: PT standard (G / NPT available). Related ACQ-family variants: ASQ (single-acting push), ATQ (single-acting pull), ACQD (double rod), ACQJ (adjustable stroke), TACQ (guided / non-rotating).

Where the Airtac ACQ140 Compact Cylinder ACQ140X50SB Is Used

factory

Automotive Stamping Press

Drives heavy blanking and forming dies where the short JIS compact footprint prevents interference with the press crown.

vertical_align_center

Pallet Elevator Actuator

Lifts loaded heavy-duty pallets in distribution hubs, utilizing the 7294.8 N pull force to lower goods smoothly.

build

Injection Mold Ejection

Pushes large molded plastic parts out of stationary platens, using the male M30x1.5 thread for robust mold coupling.

Is the Airtac ACQ140 Compact Cylinder ACQ140X50SB the Right Cylinder?

When sizing this 140 mm bore actuator, compare its 7696.9 N extend force at 0.5 MPa against the neighboring bores. Stepping down to the Ø125 yields 6135.9 N, while moving up to the Ø160 provides 10053.1 N. Keep in mind that a standard ACQ body will drift if air pressure is lost or the valve is centered; the fixed bumper only decelerates the stroke end. To safely hold a load without live pressure, integrate an external rod lock or a pilot-operated check valve.

To finalize your order for this model, confirm the 140 mm bore, 50 mm stroke, PT3/8 port, the S magnet option for AirTAC reed or electronic switches, and the B male M30x1.5 rod threading.

AirtacDistr lists every ACQ140 order code with its price on one page at https://airtacdistr.com/products/airtac-acq140-compact-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Short-body depth vs. a round-body cylinder
  • ✓ Port/thread type (PT / G / NPT)
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
  • ✓ Side load — avoid on a compact rod
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the short piston rod.
  • check Very long strokes are unsuitable for the compact body.
  • check Handle the C-clip carefully; seat it fully in its groove.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACQ140 Compact Cylinder ACQ140X50SB FAQ

This 140 mm bore double-acting cylinder provides 7696.9 N push and 7294.8 N pull at 0.5 MPa, 10775.7 N push at 0.7 MPa, and a maximum push of 1570 kgf at 1.0 MPa. The operational speed range is 30-500 mm/s.

It uses a fixed NBR elastomer bumper at each end, which is not a field-adjustable air cushion; for high kinetic energy you should slow the approach or use external shock absorbers. Furthermore, it does not hold its position if air is lost, so an external rod lock or pilot-operated check valve is required for fail-safe load holding.
