AirTAC ACQJ Series · JIS Compact Adjustable-Stroke Cylinder

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S

The AirTAC ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S is a genuine double-acting COMPACT (JIS) cylinder with an EXTERNAL adjustable stop on the extend stroke — a Ø32mm bore and 100mm full stroke. Turn the stop to fine-tune the end position on the machine without changing parts.

  • BoreØ32 mm
  • Full stroke100 mm
  • Port sizePT1/8
  • Adjuster threadM12×1.25
$63.96 $71.46Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACQJ32 stroke, mounting and version on one page All ACQJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S

The AirTAC ACQJ32X100-20S is a double-acting, double-rod JIS compact cylinder with an external threaded stop and lock nut that limits the extend end position. The full stroke is 100 mm, and the 20 mm adjustment window allows you to fine-tune the usable extend range from 80 mm up to 100 mm on the machine without changing parts. The retract stroke remains unaffected by this mechanism.

Because the piston area is unchanged, the output force is identical to a standard ACQ of the same bore. The unit features a 16 mm rod, a PT1/8 port, an M12x1.25 adjuster thread, and fixed elastomer bumpers at both ends. The built-in magnet (-S) is compatible with reed and solid-state sensors.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S Technical Specifications

ModelAirtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S
SeriesACQJ JIS compact adjustable-stroke cylinder
Bore sizeØ32 mm
Full stroke100 mm
Adjuster threadM12×1.25
Port sizePT1/8
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
Rod threadM8×1.25 (F) / M14×1.5 (B)

Specifications follow the official AirTAC ACQJ datasheet. The adjustable stop shortens the EXTEND stroke only; ACQJ is double-rod, so push is lower than a standard ACQ of this bore. Adjustable window options: 10/20/30/40/50/75/100 mm.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa302 N302 N
0.7 MPa422 N—
Max (@1.0 MPa)62 kgf

ACQJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod ACQ push of the same bore. Actual usable force is lower due to friction; size with a safety margin.

Model Code: Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S

ACQJJIS compact double-acting ADJUSTABLE-STROKE cylinder series.
32Bore size in mm.
×100Full stroke length in mm.
-0Adjustable window in mm (extend stroke can be shortened by up to this).
S / BMagnet (S) / male-thread rod (B); omit for none / female thread.

Thread: PT standard (G / NPT available). Related: ACQ (fixed stroke), ACQD (double rod), TACQ (guided / non-rotating).

Where the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S Is Used

precision_manufacturing

Machining Fixture Stops

Dial in the exact 80-100 mm extend position during CNC fixture changeovers without machining custom spacers.

package_2

Carton Folding Arms

Modify the extend reach on the fly when switching carton sizes on a packaging line, keeping motion profiles intact.

factory

Assembly Press Trial

Safely test multiple extend endpoints on an assembly press to find the optimal engagement distance before final lock-down.

Is the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S the Right Cylinder?

If your extend endpoint is fixed and never varies, a standard non-adjustable ACQ cylinder is sufficient. To order, confirm the 32 mm bore, 100 mm full stroke, 20 mm window, the -S magnet, and the default female M8x1.25 rod-end thread.

AirtacDistr lists every ACQJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-acqj32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine end-position tuning?
  • ✓ Full stroke and adjust window (mm)
  • ✓ Force at your working pressure
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the adjuster nut after setting the stop.
  • check The stop limits the EXTEND stroke only.
  • check Avoid side load on the short piston rod.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-20S FAQ

The usable extend range is 80-100 mm (100 mm full stroke minus up to 20 mm).

No. The external M12x1.25 threaded stop only limits how far the rod extends, leaving the retract stroke unaffected. The force remains identical to a standard ACQ because the piston area is unchanged, and fixed elastomer bumpers decelerate the load at both ends.
