AirTAC ACQJ Series · JIS Compact Adjustable-Stroke Cylinder

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S

The AirTAC ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S is a genuine double-acting COMPACT (JIS) cylinder with an EXTERNAL adjustable stop on the extend stroke — a Ø32mm bore and 100mm full stroke. Turn the stop to fine-tune the end position on the machine without changing parts.

  • BoreØ32 mm
  • Full stroke100 mm
  • Port sizePT1/8
  • Adjuster threadM12×1.25
$63.96 $71.46Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACQJ32 stroke, mounting and version on one page All ACQJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S

The AirTAC ACQJ32X100-30S is a double-acting JIS compact cylinder featuring an external threaded stop with a lock nut that limits the extend stroke. You get a usable extension range of 70-100mm, letting you shorten the full 100mm stroke by up to 30mm directly on your equipment. The retract stroke remains completely unaffected.

This 32mm bore unit uses a 16mm rod and PT1/8 porting. It includes a fixed elastomer bumper at each end for end-of-stroke deceleration rather than an adjustable air cushion. The -S suffix indicates a built-in piston magnet compatible with reed or electronic solid-state switches via the body grooves. Operating pressure spans 0.15-1.0MPa, with a proof rating of 1.5MPa across a -20 to +70C temperature range.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S Technical Specifications

ModelAirtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S
SeriesACQJ JIS compact adjustable-stroke cylinder
Bore sizeØ32 mm
Full stroke100 mm
Adjuster threadM12×1.25
Port sizePT1/8
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
Rod threadM8×1.25 (F) / M14×1.5 (B)

Specifications follow the official AirTAC ACQJ datasheet. The adjustable stop shortens the EXTEND stroke only; ACQJ is double-rod, so push is lower than a standard ACQ of this bore. Adjustable window options: 10/20/30/40/50/75/100 mm.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa302 N302 N
0.7 MPa422 N—
Max (@1.0 MPa)62 kgf

ACQJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod ACQ push of the same bore. Actual usable force is lower due to friction; size with a safety margin.

Model Code: Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S

ACQJJIS compact double-acting ADJUSTABLE-STROKE cylinder series.
32Bore size in mm.
×100Full stroke length in mm.
-0Adjustable window in mm (extend stroke can be shortened by up to this).
S / BMagnet (S) / male-thread rod (B); omit for none / female thread.

Thread: PT standard (G / NPT available). Related: ACQ (fixed stroke), ACQD (double rod), TACQ (guided / non-rotating).

Where the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S Is Used

precision_manufacturing

Machining Fixture Stops

Dial in the exact extend position within the 70-100mm window to clamp raw castings of varying widths on a CNC milling station without swapping hardware.

view_module

Packaging Format Changeover

Adjust the extend stroke on the fly to push different carton sizes into a sealing head, using the external stop to set precise product spacing.

factory

Assembly Press Tonnage

Set trial end positions for pressing bearings on an automated line, tweaking the 30mm window to find the exact seating depth before finalizing the cycle.

Is the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S the Right Cylinder?

If your application never requires shifting the end position, a fixed-stroke ACQ cylinder is simpler and sufficient. To order this adjustable version correctly, confirm the 32mm bore, 100mm full stroke, 30mm adjuster window, the -S magnet option, and the default female M8x1.25 rod-end thread.

AirtacDistr lists every ACQJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-acqj32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine end-position tuning?
  • ✓ Full stroke and adjust window (mm)
  • ✓ Force at your working pressure
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the adjuster nut after setting the stop.
  • check The stop limits the EXTEND stroke only.
  • check Avoid side load on the short piston rod.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-30S FAQ

The full stroke is 100mm with a -30mm window, giving a usable extend range of 70-100mm. The piston rod is 16mm, the port is PT1/8, the female rod-end thread is M8x1.25, and the external adjuster thread is M12x1.25.

No, the external threaded stop only limits how far the rod extends, so the force remains identical to a standard ACQ. The cylinder uses a fixed elastomer bumper for deceleration, not an adjustable air cushion. Also, it will not hold a load if air pressure is lost; for fail-safe load holding, you must add an external rod lock or pilot-operated check valve.
