AirTAC ACQJ Series · JIS Compact Adjustable-Stroke Cylinder

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S

The AirTAC ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S is a genuine double-acting COMPACT (JIS) cylinder with an EXTERNAL adjustable stop on the extend stroke — a Ø32mm bore and 100mm full stroke. Turn the stop to fine-tune the end position on the machine without changing parts.

  • BoreØ32 mm
  • Full stroke100 mm
  • Port sizePT1/8
  • Adjuster threadM12×1.25
$63.96 $71.46Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACQJ32 stroke, mounting and version on one page All ACQJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S

The AirTAC ACQJ32X100-40S is a double-acting JIS compact cylinder featuring an external threaded stop with a lock nut to precisely limit the extend stroke. You can tune the usable extend range from 60 mm up to the full 100 mm on the machine without swapping parts. The retract stroke remains completely unaffected by this adjustment.

It includes a built-in magnet (-S) compatible with reed or solid-state electronic switches, fixed NBR elastomer bumpers at both ends for end-of-stroke deceleration, and a PT1/8 port. The external adjuster uses an M12x1.25 thread.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S Technical Specifications

ModelAirtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S
SeriesACQJ JIS compact adjustable-stroke cylinder
Bore sizeØ32 mm
Full stroke100 mm
Adjuster threadM12×1.25
Port sizePT1/8
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
Rod threadM8×1.25 (F) / M14×1.5 (B)

Specifications follow the official AirTAC ACQJ datasheet. The adjustable stop shortens the EXTEND stroke only; ACQJ is double-rod, so push is lower than a standard ACQ of this bore. Adjustable window options: 10/20/30/40/50/75/100 mm.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa302 N302 N
0.7 MPa422 N—
Max (@1.0 MPa)62 kgf

ACQJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod ACQ push of the same bore. Actual usable force is lower due to friction; size with a safety margin.

Model Code: Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S

ACQJJIS compact double-acting ADJUSTABLE-STROKE cylinder series.
32Bore size in mm.
×100Full stroke length in mm.
-0Adjustable window in mm (extend stroke can be shortened by up to this).
S / BMagnet (S) / male-thread rod (B); omit for none / female thread.

Thread: PT standard (G / NPT available). Related: ACQ (fixed stroke), ACQD (double rod), TACQ (guided / non-rotating).

Where the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S Is Used

precision_manufacturing

Machining Fixture Stops

Dial in the exact clamping extension on a CNC machining fixture during new product introduction without machining custom spacers.

sync_alt

Packaging Changeover

Rapidly adjust the pusher end position on a packaging line when switching between different carton widths.

science

Prototype Positioning

Find the optimal trial extension distance on a test rig by threading the stop in or out until the kinematic timing is perfect.

Is the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S the Right Cylinder?

A fixed-stroke ACQ is sufficient if your end position never varies, but this ACQJ variant is essential for setups requiring frequent end-position tuning. When ordering, verify the 100 mm full stroke, the 40 mm adjustable window, the -S magnet option, and the default female M8x1.25 rod-end thread.

AirtacDistr lists every ACQJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-acqj32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine end-position tuning?
  • ✓ Full stroke and adjust window (mm)
  • ✓ Force at your working pressure
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the adjuster nut after setting the stop.
  • check The stop limits the EXTEND stroke only.
  • check Avoid side load on the short piston rod.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-40S FAQ

The usable extend range is 60-100 mm, meaning the 40 mm window allows you to shorten the 100 mm full stroke by up to 40 mm.

An external M12x1.25 threaded stop with a lock nut mechanically limits how far the rod extends. This changes the stroke length only, not the piston area, so force remains unchanged. The retract stroke is unaffected. The cylinder uses fixed NBR elastomer bumpers at both ends for deceleration rather than adjustable air cushions.
