AirTAC ACQJ Series · JIS Compact Adjustable-Stroke Cylinder

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B

The AirTAC ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B is a genuine double-acting COMPACT (JIS) cylinder with an EXTERNAL adjustable stop on the extend stroke — a Ø32mm bore and 100mm full stroke. Turn the stop to fine-tune the end position on the machine without changing parts.

  • BoreØ32 mm
  • Full stroke100 mm
  • Port sizePT1/8
  • Adjuster threadM12×1.25
$58.12 $65.62Save 11% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every ACQJ32 stroke, mounting and version on one page All ACQJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B

The AirTAC ACQJ32X100-75B is a double-acting JIS compact cylinder featuring a 32mm bore and a 100mm full stroke. An external threaded stop with a lock nut limits the extend end position, providing a usable extend range of 25-100mm without changing parts. The retract stroke remains completely unaffected.

This unit includes a male M14x1.5 piston rod end for direct load coupling and uses an M12x1.25 adjuster thread. It features a fixed NBR elastomer bumper at each end for end-of-stroke deceleration rather than an adjustable air cushion. The body retains magnetic-switch grooves for position sensing, though this specific configuration ships without a magnet. Operating pressure spans 0.15-1.0MPa with a speed range of 30-500mm/s.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B Technical Specifications

ModelAirtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B
SeriesACQJ JIS compact adjustable-stroke cylinder
Bore sizeØ32 mm
Full stroke100 mm
Adjuster threadM12×1.25
Port sizePT1/8
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
Rod threadM8×1.25 (F) / M14×1.5 (B)

Specifications follow the official AirTAC ACQJ datasheet. The adjustable stop shortens the EXTEND stroke only; ACQJ is double-rod, so push is lower than a standard ACQ of this bore. Adjustable window options: 10/20/30/40/50/75/100 mm.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa302 N302 N
0.7 MPa422 N—
Max (@1.0 MPa)62 kgf

ACQJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod ACQ push of the same bore. Actual usable force is lower due to friction; size with a safety margin.

Model Code: Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B

ACQJJIS compact double-acting ADJUSTABLE-STROKE cylinder series.
32Bore size in mm.
×100Full stroke length in mm.
-0Adjustable window in mm (extend stroke can be shortened by up to this).
S / BMagnet (S) / male-thread rod (B); omit for none / female thread.

Thread: PT standard (G / NPT available). Related: ACQ (fixed stroke), ACQD (double rod), TACQ (guided / non-rotating).

Where the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B Is Used

view_module

Modular Assembly Fixtures

Dial in the exact 25 to 100mm extend position during new product changeovers without machining custom stop spacers.

precision_manufacturing

Machine Takedown Stops

Fine-tune the end-of-stroke contact point on automated lathes to accommodate varying raw material lengths.

sync_alt

Packaging Feed Trays

Adjust the push depth on-the-fly to handle different carton sizes while keeping the full retract stroke intact.

Is the Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B the Right Cylinder?

If your extend position never needs tuning, a fixed-stroke ACQ suffices. To order this version, confirm the 32mm bore, 100mm full stroke, 75mm adjustment window, the male M14x1.5 rod thread, and that no magnet is required.

AirtacDistr lists every ACQJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-acqj32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine end-position tuning?
  • ✓ Full stroke and adjust window (mm)
  • ✓ Force at your working pressure
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the adjuster nut after setting the stop.
  • check The stop limits the EXTEND stroke only.
  • check Avoid side load on the short piston rod.
  • check Installation by qualified personnel per AirTAC docs.

Airtac ACQJ32~40 Adjustable Thin-Type Cylinder ACQJ32X100-75B FAQ

The usable extend range is 25-100mm. The force is identical to a standard ACQ of the same bore.

An external M12x1.25 threaded stop with a lock nut limits the extend stroke, while the retract stroke is unaffected. A fixed NBR bumper decelerates the piston near stroke ends. The cylinder does not hold loads on air loss; for fail-safe holding, use an external rod lock.
