Airtac B52-MD Copper-Free Multi-Position Locking Cylinder B52-MD6X5S
AirTAC B52-MD6X5S Copper-Free Multi-Position Locking Cylinder Specifications
- Model: B52-MD6X5S
- Type: Multi-position locking cylinder (copper-free design)
- Bore size: 6mm
- Stroke: 5mm
- Operating pressure: 0.05–0.8 MPa
- Locking positions: 3 fixed positions (adjustable via external stops)
- Medium temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Seal material: Fluororubber (FKM)
- Mounting type: Female thread M4×0.7 (both ends)
- Cushioning: Adjustable rubber buffer
- Weight: 85g ±2g
- Dimensions: 80mm(L) × 20mm(W) × 20mm(H)
- Protection rating: IP54 (standard), IP67 (optional)
- Lubrication: Pre-lubricated (maintenance-free design)
Compact multi-position pneumatic cylinder featuring copper-free construction for chemical-sensitive environments. Precision ground rod with chrome-plated finish ensures smooth linear motion. The three-position locking mechanism allows intermediate stops between full extension/retraction positions, controlled through external mechanical limiters.
- Pharmaceutical packaging line positioning
- Semiconductor wafer handling systems
- Micro-dosing valve actuation
- Precision optical component alignment
- Laboratory automation equipment
Installation note:
Position limiters must be secured with 0.2-0.3N·m torque. Avoid side loads exceeding 2N.
For IP67 version, use silicone-free grease on rod wiper.
| Property | Property Value |
|---|---|
| sku | B52-MD6X5S |
