Airtac F-DSUB Cable F-DSUB25F300
$34.86
Regular price
$42.36
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-DSUB25F300
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Cable assemblies, including fiber optic cables and electrical cables, serve a wide range of critical functions in industrial applications. These components are primarily utilized for control systems installation, equipment interconnection, power transmission, and signal transmission, constituting indispensable components in modern industrial and daily applications. Due to their current-carrying nature, proper installation practices must be strictly followed to ensure operational safety and reliability.
Category: Solenoid Valve Coils | Brand: AirTAC | Series: F-DSUB
Installation guidelines:
Maintain proper cable orientation (key slot alignment) during mating.
Use torque-controlled screwdriver at 0.4-0.6N·m for connector fixation.
Avoid parallel routing with power cables (>100mm separation recommended).
Category: Solenoid Valve Coils | Brand: AirTAC | Series: F-DSUB
AirTAC F-DSUB25F300 D-Subminiature Cable Specifications
- Model: F-DSUB25F300
- Connector type: 25-pin D-Sub female to female
- Cable length: 300 mm ±10 mm
- Conductor material: Oxygen-free copper (7/0.12mm×25C)
- Insulation material: PVC (UL2651 80℃ 300V)
- Shielding: Double-layer aluminum foil + tinned copper braid (85% coverage)
- Voltage rating: 300V AC/DC max
- Current capacity: 1A per contact
- Contact resistance: ≤30mΩ
- Insulation resistance: ≥1000MΩ at 500V DC
- Temperature range: -40℃ to 80℃ (operating), -55℃ to 105℃ (storage)
- Bend radius: ≥5× cable diameter
- Mating cycles: ≥500 times
- Weight: 200g ±10g
- Dimensions: 300mm(L) × 45mm(W connector) × 8mm(H cable diameter)
- Protection rating: IP40 (connectors), IP67 (cable assembly when mated)
High-density shielded cable assembly with gold-plated contacts (0.8μm min) for reliable signal transmission in EMI-sensitive environments. Features strain relief boots and color-coded screws (black anodized) for quick identification. Compatible with MIL-DTL-24308 standards.
Typical Applications:
- PLC-to-servo motor control systems
- CNC machine tool I/O connections
- Industrial robot teach pendants
- Test equipment for automotive ECUs
- Medical imaging device interfaces
- Avionics data acquisition systems
Installation guidelines:
Maintain proper cable orientation (key slot alignment) during mating.
Use torque-controlled screwdriver at 0.4-0.6N·m for connector fixation.
Avoid parallel routing with power cables (>100mm separation recommended).
| Property | Property Value |
|---|---|
| sku | F-DSUB25F300 |
