Airtac F-DSUB Cable F-DSUB25M200
Category: Solenoid Valve Coils | Brand: AirTAC | Series: F-DSUB
AirTAC F-DSUB25M200 Cable Assembly Technical Details
- Model: F-DSUB25M200
- Series: D-SUB Industrial Cable Series
- Connector type: 25-pin D-subminiature (DSUB)
- Gender configuration: Male-to-Male
- Cable length: 200 meters (±2% tolerance)
- Conductor material: Tin-plated copper conductors
- Wire gauge: 28 AWG (0.08mm²) per conductor
- Shielding: Dual-layer shielding (Al-Mylar foil + tinned copper braid)
- Insulation: PVC with 80% nominal coverage
- Jacket material: Polyurethane (PU) abrasion-resistant outer jacket
- Voltage rating: 300V AC/DC max
- Current rating: 1A per contact
- Temperature range: -40℃ to 105℃ (operational)
- Bend radius: 10× cable diameter (minimum dynamic)
- Weight: 3.2 kg/100m (linear density) | Total 6.4kg ±5%
- Dimensions: 200m (Length) × 5.8mm (Outer Diameter)
- Contact resistance: ≤30mΩ
- Insulation resistance: ≥1000MΩ/km
- Certifications: RoHS compliant, UL/cUL recognized
High-density shielded cable assembly with military-grade D-sub connectors, engineered for stable signal transmission in harsh industrial environments. Features 360° EMI/RFI protection and oil-resistant jacket with 50 million flex cycles rating. Precisely crimped contacts ensure vibration-resistant connections.
- CNC machine tool control systems
- Robotic arm servo motor interfaces
- Industrial PLC communication networks
- Test & measurement equipment clusters
- Automated warehouse sensor arrays
- Avionics data transmission systems
Installation guidelines:
Maintain minimum 150mm straight section near connectors during routing.
Use strain relief clamps every 2 meters for vertical runs.
Avoid parallel routing with power cables (maintain ≥50mm separation).
