Airtac F-DSUB Cable F-DSUB25M500
$44.16
Regular price
$51.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-DSUB25M500
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Cable assemblies, including fiber optic cables and electrical cables, serve a wide range of critical functions in industrial applications. These components are primarily utilized for control systems installation, equipment interconnection, power transmission, and signal transmission, constituting indispensable components in modern industrial and daily applications. Due to their current-carrying nature, proper installation practices must be strictly followed to ensure operational safety and reliability.
Category: Solenoid Valve Coils | Brand: AirTAC | Series: F-DSUB
Compatibility note:
Matches standard DB25 pinouts. Not recommended for PoE applications.
Maximum data rate: 10Mbps (RS-422), 115.2kbps (RS-232).
Category: Solenoid Valve Coils | Brand: AirTAC | Series: F-DSUB
AirTAC F-DSUB25M500 D-Subminiature Cable Assembly Specifications
- Model: F-DSUB25M500
- Type: High-density shielded signal cable assembly
- Connector type: DB25 male to DB25 male (25-pin)
- Cable length: 500mm ±10mm
- Conductor material: Oxygen-free copper (28AWG)
- Insulation: PVC (0.8mm thickness)
- Shielding: Dual-layer aluminum foil + tinned copper braid (85% coverage)
- Jacket material: Flexible PVC (OD 8mm)
- Voltage rating: 300V AC/DC max
- Temperature range: -40℃ to 80℃
- Contact resistance: ≤30mΩ
- Insulation resistance: ≥1000MΩ at 500VDC
- Bend radius: 50mm (dynamic), 25mm (static)
- Weight: 210g ±10g
- Dimensions:
- Connector A: 42mm(W) × 15mm(H)
- Connector B: 42mm(W) × 15mm(H)
- Cable diameter: 8mm
- Total assembly length: 584mm (including connectors)
Precision-engineered D-sub cable with gold-plated contacts (0.8μm thickness) ensures reliable signal transmission in EMI-sensitive environments. Features strain relief boots and color-coded thumbscrews (blue) for secure connections. Meets UL20276 and RoHS compliance standards.
Typical Applications:
- Industrial PLC-to-HMI communication systems
- CNC machine tool I/O connections
- Test equipment signal interfaces (oscilloscopes, data loggers)
- Broadcast studio audio/video routing
- Retrofit wiring for legacy RS-232/422 systems
Installation Guidelines:
- Route cables away from power lines (>50mm separation)
- Secure connectors with locking screws (0.4Nm torque recommended)
- Maintain minimum bend radius during installation
- Use cable ties with smooth edges for strain relief
Compatibility note:
Matches standard DB25 pinouts. Not recommended for PoE applications.
Maximum data rate: 10Mbps (RS-422), 115.2kbps (RS-232).
| Property | Property Value |
|---|---|
| sku | F-DSUB25M500 |
