The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20SB is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 80 to 100 mm on the machine — no shims, no part change.
The SDAJ32X100-20SB is a compact double-acting double-rod cylinder featuring an external M10x1.25 adjustment screw. Turning this R thread lets you dial the extend stop down from the 100mm maximum to an 80mm minimum directly on the machine, eliminating the need for shims or part swaps.
This thin riveted-body design saves valuable axial mounting depth where larger profile cylinders cannot fit. It includes a built-in piston magnet for AirTAC reed or electronic switches and a male M10x1.25 piston rod end. End-of-travel deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion.
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-20SB |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 80 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -20 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial the extend stop from 80 to 100mm via the M10x1.25 screw during machine changeover to accommodate different part heights without disassembling the actuator.
Adjust the male M10x1.25 rod extension on packaging lines to press fit cartons of varying depths, relying on the fixed NBR bumper to absorb the final impact.
Stepping down to the SDAJ25 yields 245.4N, while moving up to the SDAJ40 provides 628.3N.
This unit is ideal for setups requiring frequent on-site stroke tuning between 80 and 100mm. It carries the -S magnet for position sensing and the -B male M10x1.25 rod thread. Remember that a plain cylinder drifts when air is lost or the valve is centered; the fixed bumper only decelerates near the end and the R screw is a mechanical stop, not a lock. For secure load holding without live pressure, install an external rod lock or pilot-operated check valve.
AirtacDistr lists every SDAJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj32-adjustable-cylinder
Quick checklist
At 0.7MPa, push increases to 563N and pull to 483.8N. The theoretical maximum push is 82kgf at 1.0MPa.
The external R screw shortens the extend stroke by up to 20mm, allowing a usable range of 80-100mm; retract remains full. The included -S magnet enables position detection using AirTAC reed or electronic solid-state switches.
