The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50SB is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 50 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ32X100-50SB is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the M10x1.25 adjuster screw, you can dial the extend stroke anywhere between 50 and 100 mm directly on the machine.
Its short riveted body saves valuable axial mounting depth where larger profile cylinders cannot fit. This specific unit includes a built-in piston magnet for AirTAC reed or electronic switches and a male M10x1.25 piston rod thread. End-of-stroke deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion.
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-50SB |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 50 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 50 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -50 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial in the exact 50-100 mm extend position for varying part fixtures during machine changeover without swapping shims or cylinders.
Set precise trial extension endpoints for repetitive testing equipment, relying on the fixed NBR bumper to absorb end-of-stroke shock.
When sizing this 32 mm bore, evaluate your force needs both ways.
Choose this configuration if your application requires frequent on-site stroke tuning between 50 and 100 mm without changing parts. It features a PT1/8 port, a male M10x1.25 rod thread, and the -S magnet for position sensing. Remember that a plain cylinder does not hold its load if air pressure drops or the valve centers; the piston will drift. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve.
AirtacDistr lists every SDAJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj32-adjustable-cylinder
Quick checklist
At 0.7 MPa, push increases to 563 N and pull to 483.8 N. The theoretical maximum force is 82 kgf at 1.0 MPa.
The M10x1.25 external screw shortens the extend stroke by up to 50 mm, allowing you to set the stop anywhere between 50 and 100 mm. The included -S magnet enables position detection using AirTAC reed or electronic solid-state switches.
