The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10 is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X10-10 is a compact double-acting double-rod cylinder featuring an on-site extend stop. A front M16x1.5 adjuster screw lets you dial the outward position anywhere between 0 and 10 mm, eliminating the need for shims or part swaps during changeovers. Retract travel remains full length.
The riveted body saves axial mounting depth where longer profile cylinders fail to fit. End shock is handled by a fixed NBR bumper rather than an adjustable air cushion.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 10 mm |
| Adjustable range | 0 – 10 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×10 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial in the 0 to 10 mm outward stop to grip varied part thicknesses on a machining fixture without manufacturing custom spacers.
Fine-tune the extend endpoint on a packaging line during format changes, relying on the fixed NBR bumper to absorb the end shock.
This model suits setups needing exact outward positioning without swapping hardware.
Note that a plain actuator cannot hold a load if air pressure drops or the valve centers; the piston will drift. For secure load holding without live pressure, integrate an external rod lock or pilot-operated check valve. Confirm your bore, 10 mm stroke, 10 mm window, PT1/4 port, female M10x1.5 rod thread, and absence of a magnet for this SKU.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
Operating pressure is 0.15-1.0 MPa, speed is 30-500 mm/s, and temperature ranges from -20 to +70 C.
Turning the M16x1.5 screw shortens the extend stop by up to 10 mm, giving a usable outward range of 0-10 mm. The screw sets a mechanical stop and does not alter force. It cannot hold a load on air loss; use an external rod lock or pilot-operated check valve for that. This SKU lacks a magnet, so it cannot take a switch.
