AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B

The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.

  • BoreØ50 mm
  • Max stroke10 mm
  • Adjustable range0–10 mm
  • Adjuster threadM16×1.5
  • Port sizePT1/4
  • CushionFixed NBR bumper (both ends)
$51.61 $59.11Save 12% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ50 stroke, mounting and version on one page All SDAJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B

The AirTAC SDAJ50X10-10B is a compact double-acting double-rod cylinder engineered with an external adjustable extend stop. By turning the R (M16x1.5) screw, technicians can shorten the extend position directly on the machine, tuning the usable outward travel anywhere between 0 and 10 mm without swapping shims or parts. The retract motion remains full length.

This thin riveted-body design saves valuable axial mounting depth where a larger profile cylinder will not fit. The unit features a male M18x1.5 piston rod thread for straightforward load attachment and uses a PT1/4 air port. End-of-travel shock is managed by a fixed NBR bumper that decelerates the piston near the stroke end; it is not an adjustable air cushion. Operating speed ranges from 30 to 500 mm/s across a 0.15 to 1.0 MPa pressure range.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B Technical Specifications

ModelAirtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ50 mm
Max stroke10 mm
Adjustable range0 – 10 mm
Adjuster thread (R)M16×1.5
Port sizePT1/4
Acting typeDouble acting
Rod end threadM10×1.5 F / M18×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B

SDAJCompact double-acting cylinder with adjustable stroke.
50Bore size in mm.
×10Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B Is Used

sync_alt

Changeover Positioning

Quickly reposition the male M18x1.5 rod end during product family changeovers by turning the R M16x1.5 screw, achieving exact intermediate stops on shared tooling.

Is the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B the Right Cylinder?

When sizing this actuator, evaluate both adjacent bores against your force needs. Choose this specific model when your fixture requires exact, on-site extend tuning within that 0 to 10 mm window.

Confirm the 50 mm bore, 10 mm stroke, 10 mm adjustment window, PT1/4 port, and the male M18x1.5 rod thread suit your assembly. Note that this SKU lacks a piston magnet, so it cannot accept AirTAC reed or electronic switches; specify the -S variant if sensing is required. A plain cylinder does not hold its load on air loss or when the valve is centred, as the fixed bumper only decelerates near the end and the adjuster acts as a mechanical stop rather than a lock. For load holding without live pressure, integrate an external rod lock or a pilot-operated check valve.

AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–10 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M16×1.5 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10B FAQ

The R (M16x1.5) screw mechanically shortens the extend stop by up to 10 mm (usable range 0-10 mm) without changing the output force. This specific SKU has no magnet and cannot accept switches; adding the -S option provides a magnet for reed or electronic sensors.
