AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S

The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.

  • BoreØ50 mm
  • Max stroke10 mm
  • Adjustable range0–10 mm
  • Adjuster threadM16×1.5
  • Port sizePT1/4
  • CushionFixed NBR bumper (both ends)
$60.91 $68.41Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ50 stroke, mounting and version on one page All SDAJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S

The AirTAC SDAJ50X10-10S is a compact double-acting double-rod cylinder featuring an on-site adjustable extend stop. A built-in piston magnet enables position sensing with AirTAC reed or electronic switches. The short riveted body saves axial mounting depth where a round-body or profile cylinder will not fit.

Turning the external M16x1.5 adjuster screw dials the extend end position across a 0-10 mm window without changing parts. A fixed NBR bumper decelerates the stroke end, but is not an adjustable air cushion.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S Technical Specifications

ModelAirtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ50 mm
Max stroke10 mm
Adjustable range0 – 10 mm
Adjuster thread (R)M16×1.5
Port sizePT1/4
Acting typeDouble acting
Rod end threadM10×1.5 F / M18×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S

SDAJCompact double-acting cylinder with adjustable stroke.
50Bore size in mm.
×10Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S Is Used

precision_manufacturing

Trial Positioning

Dial the extend stop across the 0-10 mm range to find the exact contact point for a 50 kg vertical lift without machining new spacers.

view_module

Shallow Cell Integration

Leverage the short riveted body to fit high-force actuation into a tight axial footprint where standard cylinders protrude too far.

Is the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S the Right Cylinder?

Choose this model when you need on-site stroke tuning for frequent changeovers.

Confirm the 10 mm stroke, 10 mm window, PT1/4 port, and the built-in -S magnet. Remember that a plain cylinder does not hold its load on air loss or valve centring; the piston drifts and the fixed bumper only decelerates near the end. For a held load, specify an external rod lock or a pilot-operated check valve.

AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–10 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M16×1.5 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X10-10S FAQ

The M16x1.5 screw shortens the extend stop by up to 10 mm on-site, setting the end position without altering force. The included -S magnet works with AirTAC reed or electronic switches for end-of-stroke sensing.
