The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-10 is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 90 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-10 is a double-acting compact cylinder featuring an external M16x1.5 adjuster screw that lets you dial the extend stop precisely between 90 and 100 mm directly on the machine. Retract travel remains full length.
Its short riveted body saves valuable axial mounting depth where a larger profile cylinder will not fit. End-of-stroke deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot host reed or electronic switches without upgrading to the -S variant.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-10 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 90 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial the 90-100 mm extend stop during fixture swaps to accommodate varying part heights without machining new spacers.
Choose this 50 mm bore when your application sits squarely in that mid-range force band.
This model is specified with a 50 mm bore, 100 mm max stroke, a 10 mm adjustment window, and a PT1/4 port. It features a female M10x1.5 rod-end thread on a 20 mm rod. Operators needing frequent changeovers or trial positioning will benefit from the on-site tuning. Remember that a plain SDAJ does not hold position or load when air is lost or the valve is centred; the fixed bumper only decelerates near the end, so install an external rod lock or pilot-operated check valve for load holding without live pressure.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
The theoretical maximum push is 200 kgf at 1.0 MPa.
Turning the M16x1.5 external screw shortens the extend stroke by up to 10 mm, allowing usable travel between 90 and 100 mm. The screw acts as a mechanical stop and does not alter the output force.
