The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-100S is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 0 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-100S is a double-acting, double-rod compact cylinder featuring an on-site adjustable extend stop. The adjuster strictly sets the mechanical end position, so output force remains identical to a standard 50 mm bore unit.
Its short riveted body drastically cuts axial mounting depth where larger profile or round-body units cannot fit. End-of-travel shock is handled by a fixed NBR bumper rather than an adjustable air cushion. Equipped with a built-in piston magnet (-S), this model supports AirTAC reed or electronic switches for precise position sensing.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-100S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 0 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 100 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -100 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Fine-tune the flap folding position during format changeovers, relying on the fixed NBR bumper to absorb the end shock at operating speeds up to 500 mm/s.
Choose this specific unit if your fixture requires frequent changeovers or trial positioning across the full 0-100 mm window.
Verify your setup needs a PT1/4 port, a 20 mm rod, and a female M10x1.5 rod-end thread. The -S magnet enables switch mounting, but remember a plain cylinder drifts on air loss—add an external rod lock or pilot-operated check valve for load holding. Speeds run 30-500 mm/s.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
The theoretical maximum push is 200 kgf at 1.0 MPa.
The external M16x1.5 screw shortens the extend stroke by up to 100 mm, giving a usable range of 0-100 mm without altering the force. The built-in -S magnet works with AirTAC reed or electronic switches for position feedback.
