The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30 is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 70 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-30 is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the R (M16x1.5) screw, you shorten the outward stroke on-site across a 70-100 mm window, eliminating the need for shims or part swaps during commissioning. The short riveted body drastically saves axial mounting depth where a round-body or profile cylinder will not fit.
End shock is managed solely by a fixed NBR bumper, which decelerates the stroke end but is not an adjustable air cushion. This specific SKU lacks a piston magnet, so it cannot accept reed or electronic switches without upgrading to the -S variant.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 70 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 30 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -30 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial in the 70-100 mm extend stop precisely during CNC changeovers to clamp raw billets of varying widths without fabricating custom spacers.
When sizing this 50 mm bore, evaluate both neighboring options.
Choose this unit if your application requires frequent on-machine stroke tuning between 70 and 100 mm. Confirm the bore, 100 mm maximum stroke, 30 mm window, PT1/4 port, female M10x1.5 rod thread, and the absence of a magnet. Note that a plain SDAJ does not hold position or load when air is lost or the valve is centered; the fixed bumper only decelerates near the end and the R screw is a mechanical stop, not a lock. For load holding without live pressure, use an external rod lock or pilot-operated check valve.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
This 50 mm bore double-acting cylinder pushes 981.7 N and pulls 824.7 N at 0.5 MPa. At 0.7 MPa, push is 1374.4 N and pull is 1154.5 N. The theoretical maximum is 200 kgf at 1.0 MPa. The air port is PT1/4.
Turning the R (M16x1.5) screw shortens the extend end position anywhere from 100 mm down to 70 mm; retract remains full. The screw is strictly a mechanical stop and does not alter force. It cannot hold a load on air loss or when a valve is centered, as the fixed NBR bumper only decelerates near the stroke end.
