AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S

The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 70 to 100 mm on the machine — no shims, no part change.

  • BoreØ50 mm
  • Max stroke100 mm
  • Adjustable range70–100 mm
  • Adjuster threadM16×1.5
  • Port sizePT1/4
  • CushionFixed NBR bumper (both ends)
$101.19 $108.69Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ50 stroke, mounting and version on one page All SDAJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S

The AirTAC SDAJ50X100-30S is a compact double-acting double-rod cylinder engineered for on-site extend tuning. An external M16x1.5 adjuster screw lets you dial the forward stop anywhere between 70 and 100 mm without swapping shims or components.

Its short riveted body conserves valuable axial mounting depth where larger profile or round-body units cannot fit. The unit includes a fixed NBR bumper at each end to decelerate impact, and the -S option provides a built-in piston magnet for direct mounting of AirTAC reed or electronic solid-state switches.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S Technical Specifications

ModelAirtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ50 mm
Max stroke100 mm
Adjustable range70 – 100 mm
Adjuster thread (R)M16×1.5
Port sizePT1/4
Acting typeDouble acting
Rod end threadM10×1.5 F / M18×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 30 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S

SDAJCompact double-acting cylinder with adjustable stroke.
50Bore size in mm.
×100Maximum stroke length in mm.
-30Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S Is Used

precision_manufacturing

Tooling Changeover

Dial the 70-100 mm extend stop during fixture swaps to accommodate varied part heights without machining new spacers.

vertical_align_center

Pallet Positioning

Adjust the downward extend limit precisely to seat components onto pallets, relying on the fixed NBR bumper for end deceleration.

Is the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S the Right Cylinder?

Choose the 50 mm bore when your changeover routines demand precise 70-100 mm extend positioning on the machine.

Confirm your parameters: 50 mm bore, 100 mm max stroke, 30 mm adjustment window, PT1/4 port, and a female M10x1.5 rod-end thread. The -S magnet enables switch sensing, but remember a standard cylinder does not hold position on air loss or valve centring. For suspended loads, integrate an external rod lock or pilot-operated check valve, as the fixed bumper only decelerates near the end of travel and never acts as a brake.

AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 70–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M16×1.5 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30S FAQ

Turning the M16x1.5 screw shortens the extend end-position within the 70-100 mm range without affecting force. The -S code denotes a built-in piston magnet compatible with AirTAC reed or electronic switches for end-of-stroke detection.
