AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S

The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 60 to 100 mm on the machine — no shims, no part change.

  • BoreØ50 mm
  • Max stroke100 mm
  • Adjustable range60–100 mm
  • Adjuster threadM16×1.5
  • Port sizePT1/4
  • CushionFixed NBR bumper (both ends)
$101.19 $108.69Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ50 stroke, mounting and version on one page All SDAJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S

The AirTAC SDAJ50X100-40S is a double-acting compact cylinder featuring an external M16x1.5 R-thread adjuster screw that dials the extend stop anywhere between 60 and 100 mm.

Its short riveted body saves valuable axial mounting depth in tight machinery layouts. The unit includes a built-in piston magnet for AirTAC reed or electronic switches and relies on a fixed NBR bumper to decelerate the stroke end, meaning it is not an adjustable air cushion or a mid-stroke lock.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S Technical Specifications

ModelAirtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ50 mm
Max stroke100 mm
Adjustable range60 – 100 mm
Adjuster thread (R)M16×1.5
Port sizePT1/4
Acting typeDouble acting
Rod end threadM10×1.5 F / M18×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 40 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S

SDAJCompact double-acting cylinder with adjustable stroke.
50Bore size in mm.
×100Maximum stroke length in mm.
-40Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S Is Used

precision_manufacturing

Machining Clamps

Dial in the 60-100 mm extend stop during tooling changeovers to clamp raw castings securely without swapping out physical spacers.

Is the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S the Right Cylinder?

Choose this unit if your fixture requires frequent on-machine stroke tuning across a 40 mm window.

Confirm your requirements for the 50 mm bore, 100 mm maximum stroke, 40 mm adjustment window, PT1/4 port, and the -S magnet for switch sensing. Remember that a plain cylinder drifts when air is lost or the valve is centered; the fixed bumper only decelerates near the end of travel. For secure load holding without live pressure, integrate an external rod lock or a pilot-operated check valve.

AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 60–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M16×1.5 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-40S FAQ

The theoretical maximum push is 200 kgf at 1.0 MPa.

Turning the M16x1.5 R screw shortens the extend stroke by up to 40 mm, yielding a usable 60-100 mm range while retract remains full. The -S option adds a piston magnet for AirTAC reed or electronic switches to confirm position.

verified

Authorized Export Seller

Genuine AirTAC parts produced by AirTAC factory.

workspace_premium

1-Year Warranty

Covers non-human-caused product damage.

local_shipping

Fast Dispatch

Most standard models are dispatched in 3-5 days.

bolt

Fast Reply

Most inquiries answered within 7 hours.
