The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50 is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 50 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-50 is a compact double-acting double-rod cylinder engineered for on-site stroke modification. An external M16x1.5 adjuster screw lets you dial the extend stop down from the 100 mm maximum to a 50 mm minimum, eliminating the need for shims or part swaps during setup.
Housed within a short riveted body, this unit conserves axial mounting depth where space is tight. End-of-travel energy is managed solely by a fixed NBR bumper, which decelerates the piston but is not an adjustable air cushion. This specific SKU lacks a piston magnet, so it cannot host reed or electronic switches without upgrading to the -S option.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 50 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 50 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -50 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial the extend stop from 50 to 100 mm via the M16x1.5 screw when swapping machining fixtures, ensuring precise positioning without disassembling the actuator.
Lift loads of roughly 50 kg using the 0.5 MPa output, relying on the fixed NBR bumper to decelerate the downward travel at the end of the 100 mm stroke.
When sizing this actuator, evaluate your force requirements against its neighbours. Dropping down to the SDAJ40 reduces the 0.5 MPa push capacity to 628.3 N, whereas stepping up to the SDAJ63 raises it to 1558.6 N. If your application demands approximately 981.7 N of extend force and requires frequent repositioning of the end stop between 50 and 100 mm, this 50 mm bore is the optimal fit. It is particularly well-suited for trial positioning on fabrication lines where the exact extend length is dialed in during commissioning.
Confirm your parameters before ordering: a 50 mm bore, 100 mm maximum stroke, 50 mm adjustment window, and a PT1/4 port. This base configuration ships with a female M10x1.5 rod-end thread and no magnet. Remember that the fixed NBR bumper only absorbs end shock; a plain cylinder does not hold a load if air pressure drops or the valve is centred.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
At 0.7 MPa the push increases to 1374.4 N and the pull to 1154.5 N. The theoretical maximum push is 200 kgf at 1.0 MPa.
Turning the external M16x1.5 screw shortens the extend stroke by up to 50 mm, allowing the rod to stop anywhere between 50 and 100 mm. The retract stroke remains full, and the mechanism sets a mechanical stop rather than altering the force.
