AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B

The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 50 to 100 mm on the machine — no shims, no part change.

  • BoreØ50 mm
  • Max stroke100 mm
  • Adjustable range50–100 mm
  • Adjuster threadM16×1.5
  • Port sizePT1/4
  • CushionFixed NBR bumper (both ends)
$88.37 $95.87Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ50 stroke, mounting and version on one page All SDAJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B

The AirTAC SDAJ50X100-50B is a double-acting compact cylinder featuring an external M16x1.5 adjustment screw that dials the extend stop anywhere between 50 and 100 mm directly on your machine.

This variant features a male M18x1.5 piston rod thread and lacks a piston magnet, meaning it cannot accept reed or electronic switches without switching to the -S option. The short riveted body saves valuable axial mounting depth where round-body or larger profile cylinders will not fit, while a fixed NBR bumper decelerates the stroke end without acting as a lock.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B Technical Specifications

ModelAirtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ50 mm
Max stroke100 mm
Adjustable range50 – 100 mm
Adjuster thread (R)M16×1.5
Port sizePT1/4
Acting typeDouble acting
Rod end threadM10×1.5 F / M18×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 50 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B

SDAJCompact double-acting cylinder with adjustable stroke.
50Bore size in mm.
×100Maximum stroke length in mm.
-50Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B Is Used

packaging

Variable-Depth Carton Sealing

Adjust the male M18x1.5 rod end outward during size changeovers to seal different carton depths precisely, relying on the fixed NBR bumper to absorb end shock.

Is the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B the Right Cylinder?

Choose this specific model if your fixture requires frequent on-site stroke tuning between 50 and 100 mm.

Confirm the 50 mm bore, 100 mm maximum stroke, 50 mm adjustment window, and PT1/4 air port. This SKU includes the -B male M18x1.5 rod thread and has no -S magnet, so position sensing is unavailable. Remember that a plain cylinder does not hold its load on air loss or valve centering; the fixed bumper only decelerates near the end of travel. For secure load holding without live pressure, install an external rod lock or pilot-operated check valve.

AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 50–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M16×1.5 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50B FAQ

Turning the M16x1.5 R screw shortens the extend stop by up to 50 mm, giving a usable extend range of 50-100 mm. The screw is strictly a mechanical stop and does not function as a mid-stroke lock; the cylinder will drift if air pressure is lost.
