The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50S is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 50 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-50S is a compact double-acting double-rod cylinder featuring an external M16x1.5 adjustment screw that dials the extend stop from 50 to 100 mm directly on your machine.
Its short riveted body drastically saves axial mounting depth where a larger profile cylinder will not fit, while the integrated -S piston magnet supports AirTAC reed or electronic solid-state switches for precise end-position detection. End shock is managed by a fixed NBR bumper, meaning the deceleration is not user-tunable.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-50S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 50 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 50 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -50 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial the extend stop between 50 and 100 mm to find the exact contact point for a 50 kg workpiece before locking the M16x1.5 screw.
Choose the SDAJ50X100-50S specifically for setups requiring frequent on-machine stroke tuning between 50 and 100 mm.
Confirm the bore, 100 mm maximum stroke, 50 mm adjustment window, and PT1/4 port match your pneumatic supply. This unit includes the -S magnet for switch sensing and a female M10x1.5 rod-end thread. Remember that a plain cylinder does not hold its load on air loss or when the valve is centred; the fixed bumper only decelerates near the end of travel. For load holding without live pressure, install an external rod lock or a pilot-operated check valve.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
The theoretical maximum push is 200 kgf at 1.0 MPa.
The external R (M16x1.5) screw shortens the extend stroke from the 100 mm maximum down to 50 mm without shims. The -S option includes a built-in piston magnet compatible with AirTAC reed or electronic solid-state switches.
