AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB

The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 25 to 100 mm on the machine — no shims, no part change.

  • BoreØ50 mm
  • Max stroke100 mm
  • Adjustable range25–100 mm
  • Adjuster threadM16×1.5
  • Port sizePT1/4
  • CushionFixed NBR bumper (both ends)
$101.19 $108.69Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ50 stroke, mounting and version on one page All SDAJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB

The AirTAC SDAJ50X100-75SB is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. A built-in piston magnet and male-thread rod come standard on this variant. By turning the M16x1.5 adjuster screw, you can dial the forward stroke down by up to 75 mm directly at the machine, yielding a usable extend range of 25 to 100 mm without swapping shims or parts.

Because the adjuster merely sets the mechanical stop position rather than altering the piston area, output force remains identical to a standard SDA of this bore. The short riveted body saves valuable axial mounting depth where larger profile cylinders cannot fit, while a fixed NBR bumper decelerates the stroke end.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB Technical Specifications

ModelAirtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ50 mm
Max stroke100 mm
Adjustable range25 – 100 mm
Adjuster thread (R)M16×1.5
Port sizePT1/4
Acting typeDouble acting
Rod end threadM10×1.5 F / M18×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 75 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB

SDAJCompact double-acting cylinder with adjustable stroke.
50Bore size in mm.
×100Maximum stroke length in mm.
-75Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB Is Used

package_2

Flap Sealing Stations

Fine-tune the forward stroke on-site to accommodate different carton depths, using the fixed NBR bumper to absorb the end shock without altering the 50 kg vertical lift capacity.

vertical_align_center

Pallet Positioning

Leverage the 75 mm adjustment window to set precise mechanical stops for multi-tier palletizing, ensuring the male M18x1.5 rod contacts loads accurately every cycle.

Is the Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB the Right Cylinder?

Stepping down to the SDAJ40 yields 628.3 N, whereas moving up to the SDAJ63 provides 1558.6 N.

Choose this specific configuration if your fixture requires on-site stroke tuning, a male M18x1.5 rod end for external mounting, and position sensing via reed or electronic switches. Note that a plain cylinder does not hold its load upon air loss or valve centering; the piston drifts and the bumper only decelerates near the end. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve. Confirm your bore, 100 mm max stroke, 75 mm window, PT1/4 port, -S magnet, and -B male thread before ordering.

AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 25–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M16×1.5 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75SB FAQ

Turning the R (M16x1.5) screw shortens the extend end position by up to 75 mm, giving a usable forward range of 25 to 100 mm. The included -S magnet allows tracking by AirTAC reed or electronic solid-state switches.
