Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10
The AirTAC Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10 is a genuine double-acting COMPACT cylinder (Ø100mm bore) whose extend end-position is set by an external M27×2.0 adjustment screw. You can dial the stroke anywhere from 90 to 100 mm on the machine — no shims, no part change.
- BoreØ100 mm
- Max stroke100 mm
- Adjustable range90–100 mm
- Adjuster threadM27×2.0
- Port sizePT3/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10
The AirTAC SDAJ100X100-10 is a compact double-acting single-rod cylinder built for high-force applications where installation depth is restricted. Its short riveted body saves valuable axial mounting space compared to larger profile alternatives. An external R (M27x2.0) adjuster screw lets you dial the extend stop down from the 100 mm maximum to 90 mm directly on the machine, eliminating the need for shims or part swaps during changeovers.
Because the adjuster sets the mechanical stop rather than altering the piston area, output force remains identical to a standard SDA of this bore, yielding 3927 N of push at 0.5 MPa. The unit relies on a fixed NBR bumper at each end to decelerate the stroke, meaning it is not an adjustable air cushion. Operating speed spans 30-500 mm/s, and the PT3/8 port matches the 100 mm bore specifications.
Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10 Technical Specifications
| Model | Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø100 mm |
| Max stroke | 100 mm |
| Adjustable range | 90 – 100 mm |
| Adjuster thread (R) | M27×2.0 |
| Port size | PT3/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M18×1.5 F / M26×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. Force is unchanged from a standard SDA of the same bore. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Force matches a standard SDA of the same bore; the adjuster only sets the stop position, not the area. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10 Is Used
Heavy Press Fitments
Dial in the exact 90-100 mm extend stop during tooling setup to prevent over-travel when seating heavy bearings, leveraging the 3927 N push force.
Riveted Body Assembly Lines
Save axial footprint in dense machinery while making quick 10 mm stroke adjustments on the fly to accommodate slight variations in workpiece height.
Vertical Lift Stations
Lift loads up to 200.2 kg with a 2:1 margin, using the R M27x2.0 screw to fine-tune the descent end-position without changing mounting hardware.
Is the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10 the Right Cylinder?
When sizing this model, compare its 3927 N push at 0.5 MPa against adjacent bores. Stepping down to the SDAJ80 yields 2513.3 N, which may be insufficient for heavy pressing, whereas this 100 mm bore provides a safe working load of roughly 2356 N (about 60% of the 0.5 MPa figure) and a vertical lift capacity of approximately 200.2 kg with a 2:1 safety margin. Choose this specific SKU if your fixture requires on-site extend tuning between 90 and 100 mm.
Confirm your parameters: 100 mm bore, 100 mm max stroke, 10 mm adjustment window, PT3/8 port, and a female M18x1.5 rod-end thread on a 32 mm rod. Note that this base configuration lacks a piston magnet, so it cannot accept reed or electronic switches. Furthermore, a plain cylinder does not hold a load if air pressure drops or the valve centers; the fixed bumper only decelerates near the end of travel. For suspended or vertical loads, integrate an external rod lock or pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 90–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M27×2.0 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10 FAQ
This 100 mm bore double-acting cylinder delivers 3927 N push and 3524.9 N pull at 0.5 MPa, 5497.8 N push and 4934.8 N pull at 0.7 MPa, with a theoretical maximum push of 801 kgf at 1.0 MPa.
Turning the external M27x2.0 adjuster screw shortens the extend stroke by up to 10 mm, allowing you to set the end position anywhere between 90 and 100 mm. This mechanism only acts as a mechanical stop and does not alter the output force.
