AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B

The AirTAC SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B is a genuine double-acting COMPACT cylinder (Ø100mm bore) whose extend end-position is set by an external M27×2.0 adjustment screw. You can dial the stroke anywhere from 90 to 100 mm on the machine — no shims, no part change.

  • BoreØ100 mm
  • Max stroke100 mm
  • Adjustable range90–100 mm
  • Adjuster threadM27×2.0
  • Port sizePT3/8
  • CushionFixed NBR bumper (both ends)
$204.94 $212.44Save 3% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ100 stroke, mounting and version on one page All SDAJ100 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B

The AirTAC SDAJ100X100-10B is a double-acting compact cylinder featuring an external adjustable extend stop. A simple turn of the R (M27x2.0) screw lets you dial the forward end-position anywhere between 90 and 100 mm directly on the machine, eliminating the need for shims or part swaps.

This model uses a short riveted body that saves axial mounting depth where a round-body or profile cylinder will not fit. It carries a fixed NBR bumper at each end to decelerate the stroke, which is not an adjustable air cushion. This specific SKU includes a male-thread piston rod (M26x1.5) and lacks a piston magnet, meaning it cannot accept reed or electronic switches without upgrading to the -S variant.

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B Technical Specifications

ModelAirtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ100 mm
Max stroke100 mm
Adjustable range90 – 100 mm
Adjuster thread (R)M27×2.0
Port sizePT3/8
Acting typeDouble acting
Rod end threadM18×1.5 F / M26×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø100mm)

PressurePush forcePull force
0.5 MPa3525 N3525 N
0.7 MPa4935 N—
Max (@1.0 MPa)719 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B

SDAJCompact double-acting cylinder with adjustable stroke.
100Bore size in mm.
×100Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B Is Used

factory

Large Mold Changeover

Quickly adjust the forward position by up to 10 mm during mold swaps on a large assembly line, saving axial space with the compact riveted body.

Is the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B the Right Cylinder?

Choose this 100 mm option when the smaller bore cannot overcome your friction and payload, but avoid oversizing if air consumption is a primary concern.

This cylinder suits applications requiring on-site stroke tuning during setup or changeover. Remember that a plain SDAJ does not hold position or load when air is lost or the valve is centred; the fixed bumper only decelerates near the end of travel, and the screw is a mechanical stop, not a lock. For load holding without live pressure, install an external rod lock or pilot-operated check valve. Confirm your bore, stroke, 10 mm adjust window, PT3/8 port, male M26x1.5 rod thread, and lack of a magnet before ordering.

AirtacDistr lists every SDAJ100 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj100-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 90–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M27×2.0 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-10B FAQ

The external adjuster does not alter these force figures.

The R (M27x2.0) screw shortens the extend stroke by up to 10 mm, allowing you to set the forward stop anywhere between 90 and 100 mm. This -B model features a male M26x1.5 piston rod thread, and because it lacks the -S code, it has no magnet and cannot use reed or electronic switches.
