AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20

The AirTAC SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20 is a genuine double-acting COMPACT cylinder (Ø100mm bore) whose extend end-position is set by an external M27×2.0 adjustment screw. You can dial the stroke anywhere from 80 to 100 mm on the machine — no shims, no part change.

  • BoreØ100 mm
  • Max stroke100 mm
  • Adjustable range80–100 mm
  • Adjuster threadM27×2.0
  • Port sizePT3/8
  • CushionFixed NBR bumper (both ends)
$204.94 $212.44Save 3% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ100 stroke, mounting and version on one page All SDAJ100 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20

The AirTAC SDAJ100X100-20 is a double-acting compact cylinder engineered for high-force applications where axial mounting depth is restricted. Its short riveted body conserves space, while the external R (M27x2.0) adjuster screw lets you dial the extend stop directly on the machine between 80 and 100 mm without changing parts.

End-of-travel deceleration relies on a fixed NBR bumper rather than an adjustable air cushion. This SKU ships without a piston magnet, so it cannot host reed or electronic switches; order the -S variant if sensing is required. The 32 mm piston rod features a female M18x1.5 thread, and the unit operates at 30-500 mm/s.

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20 Technical Specifications

ModelAirtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ100 mm
Max stroke100 mm
Adjustable range80 – 100 mm
Adjuster thread (R)M27×2.0
Port sizePT3/8
Acting typeDouble acting
Rod end threadM18×1.5 F / M26×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 20 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø100mm)

PressurePush forcePull force
0.5 MPa3525 N3525 N
0.7 MPa4935 N—
Max (@1.0 MPa)719 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20

SDAJCompact double-acting cylinder with adjustable stroke.
100Bore size in mm.
×100Maximum stroke length in mm.
-20Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20 Is Used

factory

Compact Clamp Positioning

Fit high-force clamping into tight machine footprints using the space-saving riveted body, making minute 0-20 mm adjustments on the factory floor.

Is the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20 the Right Cylinder?

When sizing this model, evaluate your force requirements bidirectionally.

Operators who need frequent changeovers or trial positioning will benefit from the 20 mm on-site adjustment window. Confirm your specifications: 100 mm bore, 100 mm max stroke, 20 mm adjust window, PT3/8 port, no magnet, and a female rod thread. Remember that the mechanical stop does not function as a lock; if you need to hold a load without live air pressure, integrate an external rod lock or pilot-operated check valve.

AirtacDistr lists every SDAJ100 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj100-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 80–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M27×2.0 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-20 FAQ

At 0.7 MPa, push increases to 5497.8 N and pull to 4934.8 N. The theoretical maximum push is 801 kgf at 1.0 MPa.

The R (M27x2.0) screw mechanically shortens the extend stop from the 100 mm maximum down to 80 mm without altering the force output. This specific SKU lacks the -S magnet option, meaning it cannot support reed or electronic switches.
