AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75

The AirTAC SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75 is a genuine double-acting COMPACT cylinder (Ø100mm bore) whose extend end-position is set by an external M27×2.0 adjustment screw. You can dial the stroke anywhere from 25 to 100 mm on the machine — no shims, no part change.

  • BoreØ100 mm
  • Max stroke100 mm
  • Adjustable range25–100 mm
  • Adjuster threadM27×2.0
  • Port sizePT3/8
  • CushionFixed NBR bumper (both ends)
$204.94 $212.44Save 3% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ100 stroke, mounting and version on one page All SDAJ100 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75

The AirTAC SDAJ100X100-75 is a double-acting compact cylinder featuring an external adjustable extend stop. A M27x2.0 adjuster screw lets you dial the extend stroke down from the 100 mm maximum to 25 mm directly on the machine, eliminating shims or part changes during setup. The short riveted body saves axial mounting depth where a round-body or profile cylinder will not fit.

The system relies on a fixed NBR bumper at each end to decelerate the stroke, meaning it is not an adjustable air cushion. Operating pressure spans 0.15 to 1.0 MPa with a speed range of 30-500 mm/s.

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75 Technical Specifications

ModelAirtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ100 mm
Max stroke100 mm
Adjustable range25 – 100 mm
Adjuster thread (R)M27×2.0
Port sizePT3/8
Acting typeDouble acting
Rod end threadM18×1.5 F / M26×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 75 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø100mm)

PressurePush forcePull force
0.5 MPa3525 N3525 N
0.7 MPa4935 N—
Max (@1.0 MPa)719 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75

SDAJCompact double-acting cylinder with adjustable stroke.
100Bore size in mm.
×100Maximum stroke length in mm.
-75Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75 Is Used

precision_manufacturing

Heavy Press Tuning

Dial in the exact 25 to 100 mm extend contact point for a 200.2 kg vertical pressing assembly without swapping mechanical spacers.

vertical_align_center

Vertical Lift Dampening

Lift loads up to 2356 N safely; rely on the fixed NBR bumper to absorb end-of-stroke shock, adding an external absorber for high-energy cycles.

Is the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75 the Right Cylinder?

Choose this specific unit if your fixture requires on-site stroke tuning across a 25 to 100 mm window.

Confirm the bore, 100 mm stroke, 75 mm window, and PT3/8 port for your manifold. This SKU lacks the -S magnet, so it cannot accept reed or electronic switches; select the -S variant if you need position sensing. Remember that a plain cylinder does not hold its load on air loss or valve centering—the piston drifts and the fixed bumper only decelerates near the stroke end. For a held load, specify an external rod lock or a pilot-operated check valve.

AirtacDistr lists every SDAJ100 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj100-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 25–100 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M27×2.0 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X100-75 FAQ

The theoretical maximum push force is 801 kgf at 1.0 MPa.

The external M27x2.0 screw acts as a mechanical stop, allowing you to shorten the extend stroke from the 100 mm maximum down to 25 mm. It sets the end position without changing the output force, and the retract stroke remains full length.
