Genuine AirTAC adjustable mounting height stopper cylinder, order code TTG32X15K from the TTG32 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
Within the AirTAC TTG series of adjustable-height stopper cylinders, the TTG32X15K combines a 32 mm bore and a 15 mm stroke (+1.0/0 mm tolerance) with the lever roller stopper and an adjustable oil shock absorber, so pallets and workpieces are decelerated more softly than with a rigid rod end. The flange mounting lets you set the stopper height on the machine, the port is PT1/8, and the operating range is 0.2 to 1.0 MPa.
Action is single acting, pull-in: air retracts the rod, and when the supply is cut the spring extends it, so the stopper rises if air fails. This code carries no magnet, so switch-based position sensing is not available on it; order an S variant if sensing is needed. Air must be filtered by a 40 um element, and lubrication is not required.
| Order code | TTG32X15K |
|---|---|
| Product | Adjustable mounting height Stopper Cylinder |
| Stroke | 15 mm |
| Stopper | Lever roller, adjustable oil cushion |
| Magnet | No magnet |
| Action | Single acting, spring extend |
|---|---|
| Mounting | Flange, adjustable mounting height |
| Bore | Ø32 mm |
| Strokes | 10, 15, 20 mm (+1.0/0) |
| Port | PT1/8 |
| Stopper types | Round rod, Flat rod, Roller, Lever roller, adjustable oil cushion |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0.2-1.0 MPa |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Cushion | Bumper |
| Lubrication | Not required |
Source: AirTAC Products Catalog 2026A (PDF01-P0756..P0757), TTG series specifications and ordering code.
This K code pairs the 15 mm stroke with the lever roller head and adjustable oil cushion. For a rigid rod end instead, pick TTG32X15C (round rod) or TTG32X15B (flat rod); TTG32X15R gives a plain roller without the oil shock absorber. If a rebounding lever must not push the stopped load backwards, order TTG32X15KF, which adds the F self-lock to this same head. Strokes of 10 and 20 mm exist as TTG32X10K and TTG32X20K.
AirtacDistr lists every TTG32 order code with its price on one page at https://airtacdistr.com/products/airtac-ttg32-stopper-cylinder
Raises into the path of pallets on a conveyor line; the 15 mm rise catches the leading edge while the adjustable oil cushion takes the impact of the moving load.
Holds cartons at a fill or wrap station; the lever roller head gives a softer contact than a round or flat rod on light boxes.
Because the spring extends the stopper whenever air is cut, a dropped supply leaves the 15 mm stop up in the path rather than letting workpieces run past.
Bore 32 mm; stroke 15 mm with a +1.0/0 mm tolerance; stopper: lever roller with adjustable oil cushion; single acting, spring extend (air retracts, spring raises the stopper); flange mounting with adjustable height; port PT1/8; operating pressure 0.2 to 1.0 MPa; proof pressure 1.5 MPa (215 psi); temperature -20 to +70 C; bumper cushion; no magnet; no lubrication required.
Size the 32 mm bore against the impact load and speed charts in the AirTAC catalog rather than by static force alone, since a stopper cylinder absorbs moving loads. The thicker piston rod of the TTG32 resists impact better, and the adjustable oil cushion lets you tune how hard the lever roller stops the pallet; confirm the allowable impact values from the datasheet for your speed.
