AirTAC TTG32 · Adjustable mounting height Stopper Cylinder

Airtac TTG Stopper Cylinder TTG32X15SC

Genuine AirTAC adjustable mounting height stopper cylinder, order code TTG32X15SC from the TTG32 range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • Stroke15 mm
  • StopperRound rod
  • MagnetMagnet
  • ActionSingle acting, spring extend
  • MountingFlange, adjustable mounting height
  • BoreØ32 mm
$50.00 $57.50Save 13%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTG32 stroke, stopper and magnet on one page All TTG32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTG Stopper Cylinder TTG32X15SC

Order code TTG32X15SC decodes to the C round rod stopper on the 32 mm bore with a 15 mm stroke and the S magnet fitted. The round rod is the simplest head in the TTG range: workpieces sliding into it can rub or roll against the cylindrical face, which suits carton and tote stopping where a flat edge is not needed. Stopper height is set through the flange mounting, adjustable on the machine, rather than by fixed brackets.

Running figures to plan around: operating pressure 0.2-1.0 MPa with 1.5 MPa (215 psi) proof pressure, ambient from -20 to +70 C, and fluid air filtered by a 40 um element. The series needs no lubrication and follows JIS standards, and the built-in piston magnet lets external reed or hall-effect switches report stopper position to the control system.

Airtac TTG Stopper Cylinder TTG32X15SC Technical Specifications

Order codeTTG32X15SC
ProductAdjustable mounting height Stopper Cylinder
Stroke15 mm
StopperRound rod
MagnetMagnet
ActionSingle acting, spring extend
MountingFlange, adjustable mounting height
BoreØ32 mm
Strokes10, 15, 20 mm (+1.0/0)
PortPT1/8
Stopper typesRound rod, Flat rod, Roller, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.2-1.0 MPa
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0756..P0757), TTG series specifications and ordering code.

How to choose

Within the 15 mm stroke family, pick TTG32X15SC over TTG32X15SB when point or line contact is fine for your load and you want the basic head; step up to TTG32X15SR for a rolling contact that lets the load ride onto the stopper, or to TTG32X15SK when the lever roller with adjustable oil shock absorber is needed to soften impact. If position sensing is not required, the magnet-free equivalent is TTG32X15C (blank S field). Stroke alternatives on the same round rod are TTG32X10SC and TTG32X20SC.

AirtacDistr lists every TTG32 order code with its price on one page at https://airtacdistr.com/products/airtac-ttg32-stopper-cylinder

Applications

conveyor_belt

Accumulation stops on belt conveyors

The 15 mm rise lifts the round rod above the belt line to catch sliding cartons, with the adjustable flange setting the exact contact height per product.

warehouse

Tote and tote-box stopping in sortation

Light plastic totes stop cleanly on the cylindrical rod face, and the S magnet feeds stopper status to the sortation controller for downstream gating.

factory

Fixture present-and-stopped checks

On assembly lines the magnet signal lets the PLC verify the stopper is seated down before the next pallet transfer is permitted.

FAQ

What figures define the TTG32X15SC?

Bore 32 mm; stroke 15 mm (tolerance +1.0/0 mm); single acting, spring extend, pull-in type; round rod stopper (C) with magnet (S); port PT1/8; operating pressure 0.2-1.0 MPa; proof pressure 1.5 MPa (215 psi); temperature range -20 to +70 C; bumper cushion; flange mounting with adjustable height; fluid air filtered by a 40 um element; no lubrication required.

How does the magnet option change installation?

The S code puts a magnet in the piston, so reed or hall-effect switches can be clamped to the outside of the 32 mm body to detect the stopper's up and down positions - no drilling or rework of the cylinder is needed. The air circuit itself is unchanged: the single PT1/8 port retracts the rod, and the spring, not the sensor, provides the fail-safe rise when air is cut. Choose TTG32X15C if no sensing is wanted.
