AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH20X15L

Genuine AirTAC heavy duty stopper cylinder, order code TTH20X15L from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ20 mm, 15 mm stroke
  • StopperLever roller, fixed oil cushion
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$91.88 $99.38Save 7%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH20X15L

The TTH20X15L is the smallest bore in the AirTAC TTH heavy-duty stopper cylinder range: Dia 20 mm bore with its single 15 mm stroke, flange mounted, and fitted with the L lever roller stopper riding on a fixed oil cushion. It is a single acting spring-extend (pull-in) cylinder: air pressure retracts the roller below the load path, and when the air is cut the internal spring pushes the stopper back up, so a pallet is stopped even if the supply fails.

Because this is the Dia 20 size, the operating pressure band is 0.25-1.0 MPa and the air port is M5x0.8, with proof pressure of 1.5 MPa (215 psi) and a working temperature of -20 to +70 C. The fluid must be air filtered by a 40 um element, and like the whole TTH series it follows JIS standards and needs no lubrication. A threaded sensor hole takes a proximity switch at M5x0.5 on Dia 20 to Dia 40 bodies.

Airtac TTH Stopper Cylinder TTH20X15L Technical Specifications

Order codeTTH20X15L
ProductHeavy duty Stopper Cylinder
BoreØ20 mm, 15 mm stroke
StopperLever roller, fixed oil cushion
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Pick TTH20X15L when your load and conveyor speed fall inside the Dia 20 row of the catalog maximum load charts (drawn for a friction coefficient of 0.1). Note that the oil shock absorber damping is adjustable only on Dia 32 and up, so at Dia 20 the fixed oil cushion of this L version is the catalog choice rather than the K adjustable version.

If you need the lever to hold position against recoil, order TTH20X15LF, which adds the F self-lock to this same lever roller. If you need electrical position detection, TTH20X15SL carries the S magnet that this code omits, so this unit has no magnetic piston for sensing.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

Light pallet stops on compact conveyors

The Dia 20 bore with 15 mm stroke and fixed oil cushion lever roller stops small pallets on narrow conveyor lines, with the M5x0.8 port fitting tight machine frames.

check_circle

Fail-safe rise on air loss

As a spring-extend pull-in cylinder, the stopper rises when air pressure is cut, so workpieces cannot roll past the station during an emergency stop or supply failure.

sensors

Sensor-ready end detection

Even without a magnet, the threaded M5x0.5 proximity sensor hole on Dia 20 to Dia 40 bodies lets you signal stopper position to the line controller.

FAQ

What are the key figures of the AirTAC TTH20X15L?

Dia 20 mm bore, 15 mm stroke, single acting spring extend (pull-in), flange mounting, L lever roller with fixed oil cushion, air port M5x0.8, operating pressure 0.25-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, air filtered by a 40 um element, no lubrication required.

What happens to the stopper if the air supply is lost?

The TTH is pull-in: air retracts the rod and the spring extends it. Cut the supply and the spring pushes the stopper back up, so the stopped workpiece stays blocked. The thick piston rod resists impact from the arriving load, and the oil shock absorber in the lever roller absorbs the impact energy.
