AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH20X15LF

Genuine AirTAC heavy duty stopper cylinder, order code TTH20X15LF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ20 mm, 15 mm stroke
  • StopperLever roller, fixed oil cushion, self-lock
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$91.88 $99.38Save 7%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH20X15LF

TTH20X15LF takes the Dia 20, 15 mm stroke TTH stopper cylinder and adds the F option: self-lock on the lever roller. Without self-lock, a spring-extend stopper can spring back and push the stopped load backwards; the F lock prevents exactly that, holding the lever in place once it has risen under the pallet or box.

The cylinder stays single acting spring extend: air retracts the roller, the spring raises it when air is cut, giving a fail-up stop on Dia 20's 0.25-1.0 MPa supply through the M5x0.8 port. Proof pressure is 1.5 MPa (215 psi), the temperature range is -20 to +70 C, no lubrication is required, and the body accepts a proximity sensor in an M5x0.5 threaded hole. This code has no magnet.

Airtac TTH Stopper Cylinder TTH20X15LF Technical Specifications

Order codeTTH20X15LF
ProductHeavy duty Stopper Cylinder
BoreØ20 mm, 15 mm stroke
StopperLever roller, fixed oil cushion, self-lock
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Choose TTH20X15LF over the plain TTH20X15L whenever the stopped load could be shoved backwards by lever recoil or line vibration and the load charts (friction coefficient 0.1) put you in the Dia 20 band. The fixed oil cushion suits Dia 20, since the catalog makes the oil shock absorber damping adjustable only from Dia 32 upward.

Remember what this code does not include: the S magnet is absent, so magnetic piston sensing is not available here. If you want both self-lock and magnet, combine them in the same ordering code structure; if you want sensing without self-lock, TTH20X15SL is the sibling.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

pan_tool

Holding loads against push-back

The F self-lock stops the lever from springing back and pushing the stopped workpiece backwards, ideal where boxes are indexed tightly against the stopper.

forklift

Transfer car docking stations

A fail-up stopper that stays locked under the load edge suits docking points where carts or pallets arrive on Dia 20-rated conveyor branches.

inventory_2

Accumulation lane exits

In buffer lanes, the 15 mm stroke lever roller with fixed oil cushion releases and re-stops boxes without lubrication over the -20 to +70 C range.

FAQ

What does the F option change on the AirTAC TTH20X15LF?

F adds self-lock to the lever roller stopper: it stops the lever from springing back and pushing the stopped load backwards. The rest of the code stays Dia 20 bore, 15 mm stroke, L lever roller with fixed oil cushion, no magnet, M5x0.8 port, 0.25-1.0 MPa operating pressure on Dia 20.

What are the key figures of the TTH20X15LF in one place?

Dia 20 mm bore, 15 mm stroke, single acting spring extend (pull-in) with self-lock lever roller and fixed oil cushion, flange mounting, operating pressure 0.25-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, air filtered by a 40 um element, no lubrication required, proximity sensor hole M5x0.5.
