AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH25X15L

Genuine AirTAC heavy duty stopper cylinder, order code TTH25X15L from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ25 mm, 15 mm stroke
  • StopperLever roller, fixed oil cushion
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$106.98 $114.48Save 6%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH25X15L

This TTH25X15L order code selects the heavy-duty stopper cylinder in its base configuration: Dia 25 mm bore, 15 mm stroke, lever roller stopper with fixed oil cushion, and no magnet. Like all TTH cylinders it is single acting spring extend, so when the air is cut the spring pushes the stopper back up and the stop stays in place even on supply failure.

Air retracts the rod during each stop cycle while the oil shock absorber in the lever roller takes the impact energy. Operating pressure spans 0.2-1.0 MPa on this bore, a lower minimum than the Dia 20 mm version, the thicker piston rod resists impact, and no lubrication is required on air filtered by a 40 um element.

Airtac TTH Stopper Cylinder TTH25X15L Technical Specifications

Order codeTTH25X15L
ProductHeavy duty Stopper Cylinder
BoreØ25 mm, 15 mm stroke
StopperLever roller, fixed oil cushion
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Next to this base code you have two siblings: TTH25X15LF adds the F self-lock for loads that keep pushing after the stop, and TTH25X15SL adds the S magnet when you need position feedback. Stay with the plain L when a downstream valve signal is enough and the load will not kick the lever back. If adjustable damping is required, that is the K stopper, available from Dia 32 mm upward, not on this Dia 25 mm code.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

Box stop on transfer lines

Halts cartons and boxes between conveyor sections, with the fixed oil cushion lever roller absorbing arrival impact at each stop cycle.

factory

Workpiece stop before a pick station

Releases and re-stops parts at a robot pick point, triggered purely by the air valve since this code carries no magnet for sensor feedback.

widgets

Indexing small part flow

The spring extend action lifts the stop whenever air is cut, so a simple valve drop indexes or safely halts the flow of small workpieces.

FAQ

What are the key figures of the TTH25X15L?

Dia 25 mm bore, 15 mm stroke, single acting spring extend, flange mounting, port options M5x0.8, PT1/8 or PT1/4, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, bumper cushion, no lubrication required, lever roller with fixed oil cushion, no magnet.

What happens when the air supply is cut?

The TTH is pull-in: air retracts the rod to let product pass, and the internal spring extends it so the lever roller rises and stops the load. On this code the stopper is the L type with fixed oil cushion and no self-lock; if the stopped load must be held against kickback, order the F option under TTH25X15LF.
