AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH25X15LF

Genuine AirTAC heavy duty stopper cylinder, order code TTH25X15LF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ25 mm, 15 mm stroke
  • StopperLever roller, fixed oil cushion, self-lock
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$106.98 $114.48Save 6%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH25X15LF

Order code TTH25X15LF specifies the Dia 25 mm bore, 15 mm stroke stopper cylinder with lever roller, fixed oil cushion and the F self-lock. The self-lock keeps the lever from springing back and pushing the stopped load backwards after impact, which matters on accumulating conveyors where loads continue to press against the stopper.

Like every TTH unit it is single acting spring extend: air pulls the rod in to let product pass, and cutting the air raises the stopper. Damping comes from the oil shock absorber in the lever roller, the piston rod is thicker for impact resistance, and the unit needs no lubrication. No magnet is fitted under this code.

Airtac TTH Stopper Cylinder TTH25X15LF Technical Specifications

Order codeTTH25X15LF
ProductHeavy duty Stopper Cylinder
BoreØ25 mm, 15 mm stroke
StopperLever roller, fixed oil cushion, self-lock
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Compared with TTH25X15L, this code adds the self-lock; compared with the magnet version TTH25X15SL, it omits position sensing. Choose LF when loads keep pushing after the stop or when a supply failure must not let the stopper recoil and shove the load. If you need adjustable damping instead, that belongs to the K stopper on Dia 32 mm and larger bores, not to this Dia 25 mm code.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

Accumulating conveyor stop under backpressure

Holds its position when upstream loads press against the lever roller, because the self-lock prevents the stopper from springing back and pushing the load backwards.

package_2

Carton stop at a packing station

Presents cartons one at a time to packing, with the fixed oil cushion lever roller absorbing impact and the self-lock keeping the queued carton in place.

pan_tool

Load hold on air loss

The spring extend design raises the stopper when air is cut, and the self-lock ensures the returned lever does not recoil and shove the stopped workpiece.

FAQ

What are the key figures of the TTH25X15LF?

Dia 25 mm bore, 15 mm stroke, single acting spring extend, flange mounting, port options M5x0.8, PT1/8 or PT1/4, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, bumper cushion, no lubrication required, lever roller with fixed oil cushion, self-lock fitted, no magnet.

How does this code differ from TTH25X15L and TTH25X15SL?

All three share the Dia 25 mm bore, 15 mm stroke and fixed oil cushion lever roller. TTH25X15LF adds the F self-lock against kickback but has no magnet; TTH25X15SL carries the S magnet for position sensing but no self-lock; TTH25X15L is the plain base stopper with neither option.
