AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH25X15SL

Genuine AirTAC heavy duty stopper cylinder, order code TTH25X15SL from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ25 mm, 15 mm stroke
  • StopperLever roller, fixed oil cushion
  • MagnetMagnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$110.49 $117.99Save 6%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH25X15SL

In the AirTAC TTH range of heavy duty stopper cylinders, TTH25X15SL specifies the Dia 25 mm bore with its single 15 mm stroke. It is single acting, pull-in type: air retracts the rod, and when the supply is cut the spring pushes the stopper back up, so pallets and workpieces stay blocked even on loss of air pressure.

The L suffix selects the lever roller with a fixed oil shock absorber, which absorbs impact energy at a set damping rate. The S option fits a magnet, so stopper position can be tracked through the threaded sensor hole, which takes an M5x0.5 proximity sensor on bores up to Dia 40. The unit runs on air filtered by a 40 um element and needs no lubrication.

Airtac TTH Stopper Cylinder TTH25X15SL Technical Specifications

Order codeTTH25X15SL
ProductHeavy duty Stopper Cylinder
BoreØ25 mm, 15 mm stroke
StopperLever roller, fixed oil cushion
MagnetMagnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

On the Dia 25 bore, the lever roller comes only with the fixed oil cushion, since AirTAC makes the cushion damping adjustable from Dia 32 upward. Compared with ordering the plain code without the stopper suffix, this code locks in the L lever roller. If the lever must be prevented from springing back and pushing a stopped load backwards, step up to TTH25X15SLF, which adds the F self-lock to the same Dia 25 bore and 15 mm stroke while keeping the magnet.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

Pallet stop station

Mounted on a flange at the conveyor edge, the lever roller blocks passing pallets; the 15 mm stroke lifts and drops the roller as air is applied and cut.

warehouse

Carton accumulation

Boxes queue against the fixed oil cushion lever, which absorbs each impact; the magnet lets a downstream controller confirm the stopper is down before releasing flow.

factory

Workpiece indexing

On assembly lines the stopper rises automatically on air failure because the spring extends it, holding parts at the station without electrical backup.

FAQ

What are the key figures of the TTH25X15SL?

Dia 25 mm bore with a 15 mm stroke, lever roller stopper with fixed oil cushion, magnet fitted. Single acting spring extend, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, bumper cushion, no lubrication required.

How does the magnet option in this code help on the line?

The S option places a magnet in the piston, so a proximity sensor in the threaded hole (M5x0.5 on bores up to Dia 40) can report stopper position. That lets the PLC verify the roller is retracted before letting the next pallet through.
