AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH32X20K

Genuine AirTAC heavy duty stopper cylinder, order code TTH32X20K from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ32 mm, 20 mm stroke
  • StopperLever roller, adjustable oil cushion
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$123.26 $130.76Save 5%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH32X20K

The TTH32X20K is the Dia 32 mm TTH stopper cylinder with its 20 mm stroke and the K stopper: a lever roller whose oil shock absorber is adjustable. Dia 32 is the first bore where AirTAC makes the cushion damping adjustable, so deceleration can be tuned to the actual load and conveyor speed instead of accepting a fixed rate.

This code is ordered without the S magnet, so the piston carries no magnet for external switch detection. Position feedback is still possible through the threaded sensor hole, which takes an M5x0.5 proximity sensor on bores up to Dia 40. Like every TTH unit it is single acting pull-in: air retracts the stopper and the spring raises it when air is cut, with operating pressure from 0.2-1.0 MPa on this and all bores above Dia 20.

Airtac TTH Stopper Cylinder TTH32X20K Technical Specifications

Order codeTTH32X20K
ProductHeavy duty Stopper Cylinder
BoreØ32 mm, 20 mm stroke
StopperLever roller, adjustable oil cushion
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

The K suffix is what separates this code from the L versions in the same bore, such as TTH32X20SL: K gives the adjustable oil cushion, L gives a fixed rate. Omitting S means no magnet, so if electrical stopper-position feedback is needed, reorder with the magnet as TTH32X20KS. If your loads or speeds change frequently, the tunable damping here is worth it; if they are constant, a fixed cushion in the Dia 25 sibling with 15 mm stroke may suffice.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

Mixed-load pallet lines

When pallet weights vary between light empties and full loads, the adjustable oil cushion lets maintenance retune damping per zone instead of accepting one fixed deceleration.

package_2

Carton divert stations

Boxes meet the lever roller at speed; the tunable shock absorber softens the stop to protect cartons, and the spring-extend action blocks them on air loss.

settings

No-sensor mechanical control

On sections run purely mechanically, the absence of the magnet keeps the build simple; stopper state is read visually or mechanically rather than electrically.

FAQ

What are the key figures of the TTH32X20K?

Dia 32 mm bore, 20 mm stroke, lever roller with adjustable oil cushion, no magnet. Single acting spring extend, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, bumper cushion, no lubrication required.

Can the TTH32X20K report its stopper position?

Not through a magnet, since this code omits the S option and has no magnetic piston. A proximity sensor can still be screwed into the threaded sensor hole, which is M5x0.5 on bores up to Dia 40; adding the magnet at ordering gives switch detection as well.
