AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH32X20KF

Genuine AirTAC heavy duty stopper cylinder, order code TTH32X20KF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ32 mm, 20 mm stroke
  • StopperLever roller, adjustable oil cushion, self-lock
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$123.26 $130.76Save 5%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH32X20KF

This AirTAC heavy-duty stopper cylinder pairs the Dia 32 bore with its 20 mm stroke, flange mounted and built as a single acting pull-in unit: air retracts the rod to lower the lever roller, and when the air is cut the spring raises it again, so loads cannot pass a dead station. The K option fits the lever roller with an adjustable oil cushion, and Dia 32 is the first bore in the series where that damping can actually be tuned, letting you match the shock absorber to your conveyor speed.

The F letter in the order code adds the self-lock, which stops the lever from springing back and pushing the stopped workpiece backwards after impact. The cylinder runs on 0.2-1.0 MPa (proof pressure 1.5 MPa / 215 psi), works from -20 to +70 C, follows JIS standards and needs no lubrication. This variant carries no magnet, so position must be checked by external sensing rather than a magnetic switch.

Airtac TTH Stopper Cylinder TTH32X20KF Technical Specifications

Order codeTTH32X20KF
ProductHeavy duty Stopper Cylinder
BoreØ32 mm, 20 mm stroke
StopperLever roller, adjustable oil cushion, self-lock
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Pick TTH32X20KF over TTH32X20L when the fixed oil cushion of the L code does not match your line speed and you want tunable damping, and pick it over TTH32X20SK when the self-lock matters but you do not need a magnet. If stopped loads must also be monitored electrically, move up to TTH32X20SKF, which combines the K stopper, F self-lock and S magnet in one code.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

High-rate pallet stop station

On a roller conveyor where boxes arrive quickly, the lever roller takes the hit and the adjustable oil cushion is tuned on site to absorb the impact energy without bouncing the load off the stop.

pan_tool

Fail-safe hold on air loss

Because the spring raises the lever whenever air pressure is cut, a power failure or emergency stop leaves the stopper up; the self-lock then keeps it from rebounding and shoving the pallet backwards.

factory

Buffer lane between machines

In accumulation sections feeding a press or assembly cell, stopped workpieces stay put against the thick piston rod, which resists repeated impacts better than a standard cylinder rod.

FAQ

What are the key figures of the TTH32X20KF in one place?

Dia 32 mm bore with a 20 mm stroke (the single stroke offered for this bore), single acting pull-in with spring raise on air loss, flange mounting, adjustable oil cushion lever roller stopper with self-lock, no magnet. Operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, bumper cushion, air filtered by a 40 um element, no lubrication required.

Can I detect the stopper position on this version?

Not with a magnetic switch: the S magnet is not fitted on this code. The series still provides a threaded hole for a proximity sensor (M5x0.5 on Dia 20 to Dia 40 bores), so use an external proximity sensor aimed at the lever, or order TTH32X20SKF if magnetic switching is preferred.
