Genuine AirTAC heavy duty stopper cylinder, order code TTH32X20SKF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
TTH32X20SKF loads every option the Dia 32 code table offers onto one stopper cylinder: the 32 mm bore with its 20 mm stroke, the K lever roller on an adjustable oil cushion (tunable damping, available from Dia 32 upward), the F self-lock that stops the lever springing back and pushing the stopped load backwards, and the S magnet for position feedback via a magnetic switch.
As a single acting pull-in unit, air retracts the rod and the spring raises the lever whenever the supply is cut, so the stopper fails safe in the up position. It handles 0.2-1.0 MPa (proof 1.5 MPa / 215 psi) from -20 to +70 C, mounts by flange, runs on 40 um filtered air without lubrication and follows JIS standards. The thicker piston rod stands up to repeated conveyor impacts.
| Order code | TTH32X20SKF |
|---|---|
| Product | Heavy duty Stopper Cylinder |
| Bore | Ø32 mm, 20 mm stroke |
| Stopper | Lever roller, adjustable oil cushion, self-lock |
| Magnet | Magnet |
| Action | Single acting, spring extend |
|---|---|
| Mounting | Flange |
| Bore / stroke | Ø20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm |
| Port | M5×0.8 · PT1/8 · PT1/4 |
| Stopper types | Lever roller, fixed oil cushion, Lever roller, adjustable oil cushion |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Cushion | Bumper |
| Lubrication | Not required |
Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.
This is the code to order when both electric monitoring and load holding are required: TTH32X20SKF adds the self-lock that TTH32X20SK lacks, and adds the magnet that TTH32X20KF leaves out. If your conveyor speed is stable and the fixed oil cushion of TTH32X20SLF style damping would suffice, compare against the L-series code, but for variable line speeds the adjustable K cushion here is the better match.
AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder
Where stacked pallets roll into a stop with real momentum, the adjustable oil cushion absorbs the impact and the self-lock keeps the lever from rebounding and shoving the load back up the line.
The magnet drives a magnetic switch into the sensor hole (M5x0.5 thread on Dia 20 to Dia 40 bores), letting the cell controller verify the stopper is down before releasing the next unit under test.
On gravity-fed or declined sections where loads carry extra energy toward the stop, tunable damping plus self-lock and spring-raise-on-air-loss give a controlled, repeatable hold.
Dia 32 mm bore with 20 mm stroke, single acting pull-in (spring raises the lever when air is cut), flange mounting, lever roller stopper with adjustable oil cushion, self-lock fitted, magnet fitted. Operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, bumper cushion, 40 um filtered air, no lubrication needed.
The F option locks the lever roller so that, after absorbing an impact, it cannot spring back and push the already stopped workpiece backwards. That is the difference from TTH32X20SK, which shares the same bore, stroke, magnet and adjustable oil cushion but releases the lever once the cushion has done its work.
