AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH40X30KF

Genuine AirTAC heavy duty stopper cylinder, order code TTH40X30KF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ40 mm, 30 mm stroke
  • StopperLever roller, adjustable oil cushion, self-lock
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$139.55 $147.05Save 5%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH40X30KF

TTH40X30KF is the Dia 40 mm, 30 mm stroke TTH stopper cylinder built with two options together: the K lever roller on an adjustable oil cushion and the F self-lock. The self-lock stops the lever from springing back and pushing the stopped load backwards, which matters wherever a pallet or fixture presses against the roller after it halts. Adjustable damping is available at this bore since the oil shock absorber becomes adjustable from Dia 32 up.

Like every TTH, this is a single acting pull-in cylinder: compressed air retracts the rod and the spring extends it when air is lost, so the stop fails safe in the raised position. It follows JIS standards, runs without lubrication on filtered air, and its threaded sensor hole takes an M5x0.5 proximity switch. No magnet is fitted on this code.

Airtac TTH Stopper Cylinder TTH40X30KF Technical Specifications

Order codeTTH40X30KF
ProductHeavy duty Stopper Cylinder
BoreØ40 mm, 30 mm stroke
StopperLever roller, adjustable oil cushion, self-lock
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Order TTH40X30KF over the plain TTH40X30K whenever the stopped workpiece can lean back on the lever and creep backwards; the F self-lock holds the lever position instead. If tunable damping is not needed, the fixed-cushion TTH40X30L with self-lock is the lighter-duty sibling, and TTH40X30SK is the choice when magnetic position feedback matters more than load holding. Size the bore from the catalog maximum load charts, which assume a friction coefficient of 0.1.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

forklift

Pallet drop-off station

Where pallets are released toward a transfer car, the self-lock keeps the lever from being pushed back by the load, holding the pallet squarely at the stop.

warehouse

Incline feed conveyor

On lines where goods run downhill toward the stop, the F option prevents the halted box from shoving the lever rearward while the adjustable oil cushion soaks up the impact.

pan_tool

Fixture clamp-and-hold

In machining cells, a workpiece parked against the stopper stays put because self-lock resists rearward push, letting the operator work against a stable reference.

FAQ

What figures define the TTH40X30KF?

Dia 40 mm bore, 30 mm stroke, single acting spring-extend action, flange mounting, K stopper (lever roller, adjustable oil cushion) plus F self-lock, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), -20 to +70 C, 40 um filtered air, no lubrication needed, M5x0.5 proximity sensor thread, no magnet. Confirm detailed dimensions from the datasheet.

What does the self-lock actually do here?

Per the series notes, the F option stops the lever from springing back and pushing the stopped load backwards. Combined with the spring-extend fail-safe behavior of the TTH, the load is held at the stop both when air is applied and when the supply is cut.
