AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH40X30SKF

Genuine AirTAC heavy duty stopper cylinder, order code TTH40X30SKF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ40 mm, 30 mm stroke
  • StopperLever roller, adjustable oil cushion, self-lock
  • MagnetMagnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$146.52 $154.02Save 4%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH40X30SKF

The AirTAC TTH40X30SKF pairs a Dia 40 mm bore with the 30 mm stroke fixed for that size in the TTH heavy-duty stopper range, and it carries the full option stack: K lever roller with adjustable oil cushion, F self-lock and S magnet. The cylinder is single acting spring extend with flange mounting: air retracts the rod, and when supply is cut the spring extends it, so the lever rises and stops the load even on air failure.

Because this is a Dia 40 model, the threaded sensor hole takes an M5x0.5 proximity switch, and the fitted magnet lets that switch confirm rod position. Damping is adjustable on Dia 32 bores and up, so the oil cushion can be tuned to the line's impact. Supply air must be filtered by a 40 um element and no lubrication is required.

Airtac TTH Stopper Cylinder TTH40X30SKF Technical Specifications

Order codeTTH40X30SKF
ProductHeavy duty Stopper Cylinder
BoreØ40 mm, 30 mm stroke
StopperLever roller, adjustable oil cushion, self-lock
MagnetMagnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Choose this code when you want position feedback and load holding together: TTH40X30SK gives the magnet but no self-lock, TTH40X30KF gives the self-lock without the magnet, and TTH40X30K is the plain adjustable-cushion lever. Next bore sizes are Dia 50 and Dia 63, both with the same 30 mm stroke, so step up only if the maximum load charts (drawn for a friction coefficient of 0.1) demand it.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

Pallet stop on roller conveyor

The spring-extend action lifts the lever roller automatically when air is cut, and the F self-lock stops it springing back and pushing the stopped pallet backwards.

precision_manufacturing

Fixture-release check on an assembly line

The S magnet lets a switch on the rod confirm the stopper is down before the next cycle is allowed to start.

sensors

Sensor-monitored stop station

The threaded M5x0.5 hole accepts a proximity sensor aimed at the lever, complementing the magnet-based rod detection on this Dia 40 size.

FAQ

What are the key figures of the TTH40X30SKF?

Dia 40 mm bore, 30 mm stroke, single acting spring extend, flange mounting, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, K lever roller with adjustable oil cushion plus F self-lock, magnet fitted, ports M5x0.8, PT1/8 or PT1/4.

How do the F and S options work on this build?

F self-locks the lever so it cannot spring back and shove the stopped workpiece backwards, and S adds a magnet for position sensing. On Dia 20 to Dia 40 bores the sensor hole is threaded M5x0.5.
