AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH50X30K

Genuine AirTAC heavy duty stopper cylinder, order code TTH50X30K from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ50 mm, 30 mm stroke
  • StopperLever roller, adjustable oil cushion
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$148.85 $156.35Save 4%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH50X30K

The AirTAC TTH50X30K is the plain Dia 50 mm build of the TTH heavy-duty stopper family: lever roller with adjustable oil cushion, no self-lock and no magnet. The 30 mm stroke is the one stroke offered on this bore. As on all TTH sizes the action is single acting spring extend, so air pulls the stopper in and the spring raises it when supply is lost, holding parts on the line.

Stepping up to Dia 50 gives a thicker piston rod that resists impact better than the small bores, and damping is field-adjustable since Dia 32 and above allow the oil cushion to be tuned. The threaded sensor hole on Dia 50 to Dia 80 bores is M8x1.0 for a proximity switch; with no S magnet fitted, magnetic rod sensing is not available. Air must pass a 40 um filter and lubrication is not required.

Airtac TTH Stopper Cylinder TTH50X30K Technical Specifications

Order codeTTH50X30K
ProductHeavy duty Stopper Cylinder
BoreØ50 mm, 30 mm stroke
StopperLever roller, adjustable oil cushion
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

This code suits buyers who want the adjustable cushion but neither extra option: TTH50X30KF adds the F self-lock, TTH50X30S adds the magnet, TTH50X30SKF combines both, and TTH50X30L switches to the fixed oil cushion. Bore neighbours are Dia 40 and Dia 63, both sharing the 30 mm stroke; pick Dia 50 only if the load charts (friction coefficient 0.1) put Dia 40 at its limit.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

factory

Heavy pallet accumulation

The Dia 50 rod stands up to repeated impacts from loaded pallets, with the adjustable oil cushion tuned to line speed.

package_2

Carton gating before a case packer

Air pulls the stopper in to release one box at a time; if air fails, the spring lifts the lever and halts flow safely.

warehouse

Order staging stop on a sortation conveyor

The M8x1.0 threaded hole takes a proximity sensor on the lever, giving a simple stopped/not-stopped signal without a piston magnet.

FAQ

What are the key figures of the TTH50X30K?

Dia 50 mm bore, 30 mm stroke, single acting spring extend, flange mounting, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, K lever roller with adjustable oil cushion, no self-lock, no magnet, ports M5x0.8, PT1/8 or PT1/4.

Since there is no magnet, can I still sense the stopper?

Yes, indirectly: every TTH has a threaded hole for a proximity sensor, and on Dia 50 to Dia 80 bores it is M8x1.0. What you lose without the S option is magnetic detection of the piston rod position.
